1

00:00:00,500 --> 00:00:05,133

Hello everyone, today we are going to introduce PWM output voltage adjustment

2

00:00:06,233 --> 00:00:10,700

First, let's look at the FB pin of a PWM chip

3

00:00:12,800 --> 00:00:15,733

This pin is called the feedback regulating pin

4

00:00:16,133 --> 00:00:22,466

It is connected to the back end of the inductor by connecting the resistor and the series partial voltage,

5

00:00:23,866 --> 00:00:28,400

which is used to detect whether the output voltage of the inductor is normal

6

00:00:30,200 --> 00:00:34,900

The voltage at the back of the inductor, divided in series through a resistor,

7

00:00:36,600 --> 00:00:40,500

is sampled and compared to a reference voltage inside the chip

8

00:00:42,700 --> 00:00:49,100

The reference voltage inside the chip is defined by each chip manufacturer and varies from chip to chip

9

00:00:54,100 --> 00:01:01,100

If the sampled voltage is less than the internal reference voltage, it will increase the PWM output

10

00:01:04,633 --> 00:01:08,600

If the sampled voltage exceeds the internal reference voltage,

11

00:01:09,066 --> 00:01:12,466

the chip considers that the output is overvoltage

12

00:01:13,100 --> 00:01:19,700

The chip then controls the conduction of the upper and lower tubes, reducing the output voltage

13

00:01:20,933 --> 00:01:23,566

This is called feedback regulation

14

00:01:24,466 --> 00:01:29,000

FB pins of some chips can be grounded or connected to power supply,

15

00:01:29,966 --> 00:01:34,233

which is used to set the fixed voltage of PWM output

16

00:01:35,166 --> 00:01:40,900

For details, you need to consult the pin definition in the chip data manual

17

00:01:42,233 --> 00:01:44,566

We have a formula here: Vout=VFB*(1+R1/R2)

18

00:01:46,000 --> 00:01:52,300

At the same time, we can also adjust the output voltage by changing the resistance value

19

00:01:56,433 --> 00:02:00,166

Ok, so this is the introduction of the feedback regulation
