Hello everyone, today we are going to understand the PWM output voltage and current detection

2

00:00:11,033 --> 00:00:15,800

First of all, this PWM chip has an OUT pin inside

3

00:00:18,900 --> 00:00:22,500

It's not an output pin, it's a voltage input pin,

4

00:00:23,033 --> 00:00:25,700

and we call it a voltage detection input pin

5

00:00:29,400 --> 00:00:33,000

It is different from OUT in the LDO power supply mode

6

00:00:37,900 --> 00:00:41,900

In the LDO power supply mode, VOUT means output

7

00:00:44,633 --> 00:00:52,033

But the OUT, VOUT or VO pin in the PWM circuit is the voltage detection input pin,

8

00:00:53,800 --> 00:01:00,933

which is used to detect whether the voltage output at the back end of the inductor is overvoltage or undervoltage

9

00:01:02,133 --> 00:01:05,466

We often see OVP and UVP in the data books

10

00:01:08,133 --> 00:01:16,600

OVP stands for overvoltage protection, O is over, V is voltage, and P is protection

11

00:01:21,233 --> 00:01:24,666

UVP stands for undervoltage protection

12

00:01:29,600 --> 00:01:35,400

It is usually 115% above its set voltage, which is considered overvoltage,

13

00:01:36,066 --> 00:01:39,833

and below 70%, which is considered undervoltage

14

00:01:44,666 --> 00:01:47,733

Next, let's look at the current detection method

15

00:01:50,300 --> 00:01:52,600

There are two current detection methods

16

00:01:53,200 --> 00:01:57,533

The first is to connect a milliohm resistor at the back of the inductor

17

00:01:58,833 --> 00:02:07,166

The chip has CSP and CSN pins, where CS stands for current sense, P is positive, N is negative

18

00:02:11,600 --> 00:02:17,866

The CSP and CSN pins are the positive-end and negative-end input pins for current detection,

19

00:02:18,400 --> 00:02:21,600

which are connected to the output at the back of the inductor

20

00:02:23,566 --> 00:02:28,866

The voltage at the output of the inductor needs to flow through the resistor to the back stage

21

00:02:30,233 --> 00:02:32,333

If the rear stage is short-circuited or overcurrent,

22

00:02:33,700 --> 00:02:37,066

the current flowing through this resistor is enormous

23

00:02:37,400 --> 00:02:40,766

The chip calculates the current flowing through a resistor

24

00:02:40,766 --> 00:02:44,366

by detecting the voltage difference between the front and rear ends

25

00:02:52,733 --> 00:02:56,866

Therefore, there is a calculation formula: (CSP-CSN)/R=I,

26

00:02:57,433 --> 00:03:00,100

which is used to calculate the output current

27

00:03:09,266 --> 00:03:11,933

This is a very common current detection method,

28

00:03:12,266 --> 00:03:15,733

which is used by the charging chip to detect the charging current

29

00:03:17,933 --> 00:03:24,133

The second way is to judge its output current by detecting the voltage difference between the phase pin and GND

30

00:03:28,400 --> 00:03:32,333

This detection method is to detect the current flowing through the MOS tube

31

00:03:32,333 --> 00:03:36,566

when the current tube is conductive to the inductor to form the discharge loop

32

00:03:43,400 --> 00:03:48,766

The MOS tube has an internal resistance of about 10 milliohm in the state of conduction

33

00:03:54,166 --> 00:03:55,866

When the current pipe is on,

34

00:03:56,500 --> 00:04:00,766

the phase pin and PGND pin will detect the voltage difference between the D pole

35

00:04:00,766 --> 00:04:04,833

and the S pole of the lower pipe to determine the output current

36

00:04:07,633 --> 00:04:10,266

Okay, this is the second method of detection

37

00:04:12,300 --> 00:04:15,600

This is the PWM output voltage, current detection
