1

00:00:00,433 --> 00:00:05,500

Hello, everyone, today we are going to learn about the common pin definitions of PWM circuit

2

00:00:12,633 --> 00:00:14,900

First, let's look at the chip

3

00:00:19,466 --> 00:00:21,866

If we don't know the definitions of the pins,

4

00:00:22,266 --> 00:00:23,933

we don't know the meanings of them

5

00:00:28,300 --> 00:00:30,733

Let's look at the driver of the upper tube first.

6

00:00:33,700 --> 00:00:39,733

Common names are UGATE, DH, HDRV, DRVH, and so on

7

00:00:41,200 --> 00:00:42,333

So in this chip,

8

00:00:42,900 --> 00:00:48,266

the symbols DRVH on pin 21 and pin 10 are both upper tube drives

9

00:00:55,466 --> 00:01:02,633

Lower tube drive pins: LGATE, DL, LDRV, DRVL......

10

00:01:04,966 --> 00:01:10,700

In this chip, the pin 12 is DRVL, and the pin 19 is DRVL,

11

00:01:12,833 --> 00:01:14,933

both of which are lower tube drives

12

00:01:18,800 --> 00:01:23,266

The self-lift pin, which is the pin that powers the G pole of the upper tube

13

00:01:25,800 --> 00:01:32,033

Common names are BOOT, BST, VBST, BOOST, and so on

14

00:01:38,900 --> 00:01:44,966

In this chip, pins 9 and 22 VBST are both self-lift voltage pins,

15

00:01:45,400 --> 00:01:48,666

externally connected to a bootstrap capacitor

16

00:01:52,366 --> 00:01:58,566

FB, VSET, these are feedback regulation and voltage setting pins

17

00:01:59,400 --> 00:02:05,066

In this chip, both pins 2 and 5 are FBs, feedback regulation pins

18

00:02:09,300 --> 00:02:15,733

OUT, VOUT, VO, these are called output voltage detection input pins

19

00:02:16,866 --> 00:02:20,166

This corresponds to the pins 1 and pin 6 of the chip

20

00:02:22,200 --> 00:02:28,400

PHASE, SW, LX and LL are called phase pins

21

00:02:31,000 --> 00:02:36,400

They are connected to the front end of the inductor and can also be used to detect the current

22

00:02:37,166 --> 00:02:40,866

LL of pin 11 and pin 20 are phase pins

23

00:02:46,733 --> 00:02:52,700

CSP and CSN are called current detection pins, connected with the detection resistor

24

00:02:55,333 --> 00:03:01,666

This method of current detection is not used in this chip, so this chip does not have these two pins

25

00:03:04,333 --> 00:03:13,700

ILIM, TRIP, CS, OC, OCSET, these are called limit current setting pins,

26

00:03:14,766 --> 00:03:18,333

also called overcurrent protection threshold setting pins

27

00:03:25,133 --> 00:03:31,966

In this chip, the 14th TRIP2 and the 17th TRIP1 are the limit current setting pins

28

00:03:37,966 --> 00:03:46,133

SKIP, SKIPSEL, DEM, CCM, these are called working mode setting pins

29

00:03:47,833 --> 00:03:50,100

This chip does have these pins

30

00:03:57,500 --> 00:03:59,300

All right, let's continue to look

31

00:04:01,333 --> 00:04:09,033

TON, RT, RF, FSET, FS, these are called frequency setting pins

32

00:04:10,233 --> 00:04:15,400

The fourth pin here, TONSEL, is the frequency setting pin,

33

00:04:17,133 --> 00:04:20,766

which is used to set the pulse frequency of the PWM

34

00:04:22,200 --> 00:04:27,966

COMP is feedback compensation, used to correct the error of the feedback circuit

35

00:04:28,733 --> 00:04:30,466

There's no such pin here

36

00:04:32,733 --> 00:04:37,966

VSEN and ISEN, which are voltage detection and current detection pins,

37

00:04:38,800 --> 00:04:41,766

are commonly found in CPU power supply circuits

38

00:04:43,733 --> 00:04:47,333

Ok, these are the common pin definitions of PWM circuit
