Hello everyone, today we are going to learn a typical dual PWM controller workflow

2

00:00:07,300 --> 00:00:11,033

First, let's take this common standby chip as an example

3

00:00:15,600 --> 00:00:19,566

For a chip to work, the first step needs to meet the power supply,

4

00:00:20,800 --> 00:00:23,966

so the first step in the workflow is the power supply

5

00:00:25,100 --> 00:00:29,200

Here, pins 15 and 16 are the power input pins

6

00:00:34,166 --> 00:00:37,066

The second step, it needs to be enabled

7

00:00:37,833 --> 00:00:44,700

With EN1, the opening of channel 1 will turn on the first PWM output

8

00:00:46,200 --> 00:00:50,700

The V0 pin is used to detect whether the output voltage is normal,

9

00:00:59,500 --> 00:01:04,066

and the FB pin is used to feedback and adjust the output voltage

10

00:01:06,333 --> 00:01:11,300

When the output voltage is normal, the PG signal will be generated

11

00:01:14,966 --> 00:01:18,200

When it gets the opening signal of the second channel,

12

00:01:19,833 --> 00:01:26,033

it will control the second channel PWM circuit to work, and generate PWM output

13

00:01:29,166 --> 00:01:31,333

After the second PWM output,

14

00:01:32,933 --> 00:01:39,266

the V0 pin is used to detect whether the output voltage is overvoltage or undervoltage

15

00:01:40,200 --> 00:01:44,800

At the same time, it needs to adjust its voltage through the FB pin

16

00:01:45,533 --> 00:01:52,833

When its output voltage is stable, the chip will delay to open and leak out the second PG signal

17

00:01:53,466 --> 00:01:56,066

PG here means a good power signal

18

00:02:01,433 --> 00:02:04,633

This is the workflow of the dual PWM controller

19

00:02:06,366 --> 00:02:12,533

The so-called dual PWM controller means that the chip can control two PWM outputs

20

00:02:14,000 --> 00:02:17,833

Okay, so that's the typical dual PWM controller workflow
