Hello everyone, today we are going to learn about the PWM circuit working mode

2

00:00:06,200 --> 00:00:11,033

Most PWM circuit chip in laptop mainboards can work in two different modes

3

00:00:12,300 --> 00:00:14,866

They are PWM mode and SKIP mode

4

00:00:17,866 --> 00:00:22,933

SKIP mode is also called SKIP pulse mode, or interval mode

5

00:00:24,066 --> 00:00:27,033

Most PWM chips work in both modes

6

00:00:29,700 --> 00:00:35,400

The purpose of these two modes is to adapt to different sleep state output different current

7

00:00:37,666 --> 00:00:39,833

The standby chip, for example,

8

00:00:40,200 --> 00:00:45,600

is in standby state until the adapter is plugged in and the switch is not pressed

9

00:00:47,866 --> 00:00:50,166

The system needs small current,

10

00:00:54,466 --> 00:01:02,066

at this time, it can work in skip mode, such as 3.3V standby, 5V standby

11

00:01:03,700 --> 00:01:09,166

In the standby state, it only needs to satisfy the normal work of the standby circuit

12

00:01:11,433 --> 00:01:18,800

In standby state, CPUs, graphics cards and many other high-power chips have not started to work,

13

00:01:20,600 --> 00:01:23,066

so the power consumption is very small

14

00:01:23,600 --> 00:01:31,833

Then 3.3V standby and 5V standby do not need to output large current, they can work in SKIP mode

15

00:01:32,500 --> 00:01:37,000

The output current is small, but the output voltage is constant

16

00:01:42,800 --> 00:01:46,133

When we press the switch, after the system runs,

17

00:01:46,366 --> 00:01:51,600

the high current can meet the CPU, graphics card and other chips normal work

18

00:01:55,800 --> 00:02:01,333

At this time, 3.3V, 5V will need to work in the PWM mode

19

00:02:04,966 --> 00:02:08,500

In this mode, its output current increases,

20

00:02:08,900 --> 00:02:11,333

but the output voltage remains the same

21

00:02:14,133 --> 00:02:18,066

Through the oscilloscope to observe the inductor front-end waveform,

22

00:02:18,233 --> 00:02:19,400

we can see it

23

00:02:24,166 --> 00:02:29,333

In the PWM mode, by observing the pulse waveform of the upper and lower tubes,

24

00:02:29,500 --> 00:02:33,400

it can be seen that the boot state work in the PWM mode

25

00:02:40,666 --> 00:02:42,333

The pulse is very close

26

00:02:46,433 --> 00:02:49,800

In SKIP mode, the pulse is intermittent

27

00:02:54,000 --> 00:02:59,066

For example, this pulse period and the next pulse period are continuous,

28

00:03:00,133 --> 00:03:01,666

there is no interval

29

00:03:08,000 --> 00:03:13,766

And in SKIP mode, SKIP mode refers to the shutdown state, standby time

30

00:03:15,433 --> 00:03:19,166

There's a dead zone between one of its periods and the other

31

00:03:22,000 --> 00:03:29,433

In this dead zone state, the upper tube G pole has no high voltage and the lower tube G pole is also low level

32

00:03:31,533 --> 00:03:34,500

There is an interval between one pulse and the next,

33

00:03:35,500 --> 00:03:39,666

which we call the interval, and this is called SKIP mode

34

00:03:41,400 --> 00:03:45,800

It obviously operates in different frequencies in these two modes

35

00:03:47,500 --> 00:03:51,900

That is, in SKIP mode, it takes a break every cycle,

36

00:03:55,766 --> 00:04:01,300

and neither the upper tube nor lower tube is working, and that's called the pulse interval

37

00:04:02,266 --> 00:04:09,300

But in PWM mode, in the boot state, the upper and lower tube G pole is a continuous pulse,

38

00:04:11,000 --> 00:04:13,333

there is no dead zone in the middle

39

00:04:16,400 --> 00:04:21,333

When the upper tube G is extremely high, the lower tube G pole is low

40

00:04:21,600 --> 00:04:26,400

When the lower tube G is extremely high, the upper tube G pole is low

41

00:04:27,366 --> 00:04:31,833

So continuous, with no gaps, no dead zones

42

00:04:33,333 --> 00:04:41,266

Therefore, in PWM mode, its operating frequency is relatively high, the output current is relatively large

43

00:04:45,433 --> 00:04:49,100

In SKIP mode, its operating frequency is relatively low,

44

00:04:49,700 --> 00:04:53,900

the output current is small, but the output voltage is unchanged

45

00:04:55,933 --> 00:04:59,200

Ok, so that's the working mode of PWM circuit
