Hello everyone, today let's learn about the standby condition of the Apple EC

2

00:00:06,266 --> 00:00:08,833

This lesson is divided into two parts,

3

00:00:09,333 --> 00:00:11,700

one is the introduction of Apple EC,

4

00:00:12,500 --> 00:00:15,466

the other is the standby condition of Apple EC

5

00:00:17,000 --> 00:00:20,466

First, let's take a look at the introduction of Apple EC

6

00:00:21,600 --> 00:00:24,200

EC refers to embedded controller,

7

00:00:25,700 --> 00:00:30,866

it is a single chip microcomputer, we can also call it MCU

8

00:00:31,766 --> 00:00:37,300

The EC controls the timing of most important signals during system startup

9

00:00:38,766 --> 00:00:40,266

In the shutdown state,

10

00:00:40,366 --> 00:00:44,266

the EC keeps running and waits for the user's startup information

11

00:00:49,133 --> 00:00:56,566

After being turned on, the EC controls various indicators, fans and other devices

12

00:00:57,700 --> 00:01:02,200

It even controls the standby, sleep and other states of the system,

13

00:01:02,500 --> 00:01:05,966

and monitors the voltage and current of each supply

14

00:01:06,533 --> 00:01:11,133

There is a slight difference between the Apple EC and the normal laptop EC

15

00:01:12,466 --> 00:01:16,700

Apple's EC doesn't have a management for keyboard or touchpad,

16

00:01:17,900 --> 00:01:21,133

and Apple's EC comes with built-in programs

17

00:01:23,266 --> 00:01:29,533

During the maintenance, if the EC is to be replaced, the same board must be found

18

00:01:37,533 --> 00:01:41,233

Ok, let's take a look at the standby condition of the Apple EC

19

00:01:42,866 --> 00:01:47,766

The standby conditions of Apple EC are divided into four categories

20

00:01:48,133 --> 00:01:54,933

They are standby power supply, standby clock, standby reset, and EC program

21

00:01:58,066 --> 00:02:02,233

First of all, the standby power supply is 3.3V,

22

00:02:02,933 --> 00:02:08,600

and the common names in the circuit diagram are VBAT and VDDA

23

00:02:11,666 --> 00:02:19,600

It is usually provided by PP3V42_G3H, or PP3V3_G3H

24

00:02:20,600 --> 00:02:25,566

The standby clock of the EC is provided by a 12MHz crystal,

25

00:02:27,800 --> 00:02:30,833

which is usually located next to the EC

26

00:02:34,800 --> 00:02:40,200

The standby reset of the EC is usually named RST* in the circuit diagram,

27

00:02:44,833 --> 00:02:49,566

and the external name is usually SMC_RESET_L

28

00:02:58,133 --> 00:03:01,833

This signal is usually high at 3.3V

29

00:03:05,066 --> 00:03:08,200

If it is low, the EC will be reset

30

00:03:15,833 --> 00:03:19,033

The EC program is stored inside the EC

31

00:03:21,833 --> 00:03:27,566

After the EC meets the requirements of standby power supply, clock, and reset,

32

00:03:28,066 --> 00:03:32,900

it needs to read its own internal program to configure its GPIO pin,

33

00:03:34,333 --> 00:03:36,100

and then it can work normally

34

00:03:37,433 --> 00:03:40,700

GPIO refers to General Purpose Input Output pins

35

00:03:41,566 --> 00:03:44,166

Before the GPIO pin is configured,

36

00:03:44,966 --> 00:03:48,800

It is in a high resistance, uncontrolled state

37

00:03:51,900 --> 00:03:55,266

Ok, so that's the standby condition of the Apple EC
