1

00:00:00,266 --> 00:00:04,766

Hello everyone, today we are going to learn about the LPC bus of Apple EC

2

00:00:10,500 --> 00:00:13,000

This lesson is divided into two parts

3

00:00:13,766 --> 00:00:19,600

introduction to Apple EC's LPC bus and Apple EC's LPC bus conditions

4

00:00:23,033 --> 00:00:27,866

First, let's take a look at the introduction to the Apple EC's LPC bus

5

00:00:28,833 --> 00:00:33,600

The EC in the Apple mainboard connects to the chipset through the LPC bus,

6

00:00:34,033 --> 00:00:36,100

which is like this architecture

7

00:00:40,333 --> 00:00:44,100

The EC is connected to the PCH through the LPC bus

8

00:00:45,666 --> 00:00:50,200

and also to a diagnostic interface, DEBUG,

9

00:00:51,300 --> 00:00:55,433

for connecting diagnostic cards or diagnostic devices

10

00:01:00,800 --> 00:01:04,766

The LPC bus conditions of Apple EC are divided into:

11

00:01:04,866 --> 00:01:13,266

LPC bus power supply, LPC bus clock, reset, address data composite line and frame period

12

00:01:18,800 --> 00:01:26,600

The LPC bus supply is commonly known as VDD in circuit diagrams, and the voltage is 3.3V

13

00:01:30,366 --> 00:01:37,766

The LPC bus clock is commonly named LPC_CLK24M_SMC in circuit diagrams,

14

00:01:43,533 --> 00:01:47,566

which represents the 24M LPC bus clock frequency

15

00:01:49,200 --> 00:01:52,600

This pin is the 24M LPC bus clock pin

16

00:01:56,166 --> 00:02:01,166

The common name for LPC bus reset is SMC_RESET_L

17

00:02:01,433 --> 00:02:04,166

and the voltage is 3.3V,

18

00:02:05,766 --> 00:02:08,400

which is the pin in the circuit diagram

19

00:02:14,366 --> 00:02:18,400

Next is the address data composite line of the LPC bus

20

00:02:19,366 --> 00:02:24,200

This is used to transmit address data between the EC and the PCH

21

00:02:30,966 --> 00:02:36,066

It is bidirectional communication, there are four lines in total

22

00:02:37,666 --> 00:02:44,500

LPC_AD0, LPC_AD 1, LPC_AD2, and LPC_AD3.

23

00:02:47,500 --> 00:02:50,833

From 0 to 3, there are four lines in total

24

00:02:53,866 --> 00:03:01,100

Finally, the frame period, commonly known as LPC_FRAME_L

25

00:03:03,433 --> 00:03:06,100

This is the pin in the circuit diagram

26

00:03:10,600 --> 00:03:13,666

This signal is also active at low level

27

00:03:15,400 --> 00:03:20,566

When it is low, indicates to start or end an LPC data transfer

28

00:03:26,100 --> 00:03:30,400

The preceding LPC bus power supply, LPC bus clock,

29

00:03:31,233 --> 00:03:36,266

and LPC bus reset are necessary conditions for the LPC bus to work

30

00:03:38,700 --> 00:03:41,900

During data transmission, we can measure the waveform

31

00:03:41,900 --> 00:03:47,833

on the address data composite line and frame period signal line of the LPC bus

32

00:03:52,466 --> 00:03:57,166

At the same time, we can connect the diagnosis card on the LPC bus

33

00:03:57,533 --> 00:04:02,033

to observe the self-check process of the mainboard in the soft start process

34

00:04:08,133 --> 00:04:10,533

Well, that's the EC's LPC bus
