Hello everyone, today we are going to learn about the control of backlight in ordinary laptop EC

2

00:00:08,500 --> 00:00:11,133

This lesson is divided into two parts,

3

00:00:12,166 --> 00:00:17,600

which are the introduction of Hall components and the control signal of the EC to the backlight

4

00:00:22,633 --> 00:00:28,433

Firstly, Hall element is a kind of magnetic sensor based on Hall effect,

5

00:00:29,366 --> 00:00:31,933

also called magnetic induction element

6

00:00:33,366 --> 00:00:37,766

It has a VIN pin, a GND pin, and an OUT pin

7

00:00:38,033 --> 00:00:42,466

VIN is the power supply, provided by 3.3V standby voltage,

8

00:00:42,900 --> 00:00:46,166

GND is the ground, OUT is the output pin,

9

00:00:46,566 --> 00:00:48,733

the external name is LID#

10

00:00:53,366 --> 00:00:57,433

When there is no magnetic field, or no magnet near the chip,

11

00:01:01,366 --> 00:01:05,166

its output pin outputs a high level of 3.3V

12

00:01:08,400 --> 00:01:11,666

When there is a magnet or a magnetic field near it,

13

00:01:14,200 --> 00:01:18,166

it will pull the output pin low ground, output low level

14

00:01:21,500 --> 00:01:25,100

This Hall element in the mainboard is a 3-pins chip,

15

00:01:26,500 --> 00:01:30,500

its appearance is similar to the ordinary transistor and MOS tube

16

00:01:33,833 --> 00:01:37,766

Next, let's take a look at the EC's control of backlighting

17

00:01:38,366 --> 00:01:40,833

Here we introduce three kinds of signals

18

00:01:41,066 --> 00:01:43,100

One is the LID signal,

19

00:01:43,700 --> 00:01:46,866

which is also called the lid switch or the sleep switch

20

00:01:52,166 --> 00:01:57,133

In the shutdown state, this signal is used to determine whether it can be turned on

21

00:02:01,333 --> 00:02:06,466

When the signal is low, that is, when a magnet holds on to it,

22

00:02:07,733 --> 00:02:09,733

the machine will not turn on

23

00:02:12,100 --> 00:02:16,500

There's a magnet on the border of the screen, and when we close the cover,

24

00:02:17,300 --> 00:02:22,200

the magnet grabs the Hall element, pulling down the LID# signal

25

00:02:24,433 --> 00:02:27,366

When the EC gets this low LID# signal,

26

00:02:28,666 --> 00:02:31,700

the EC knows that the machine is in sleep state

27

00:02:34,100 --> 00:02:37,800

At this time, EC does not allow startup

28

00:02:39,300 --> 00:02:46,433

After boot, if the LID# signal is pulled down again, the EC will turn off the backlight

29

00:02:48,533 --> 00:02:55,200

After receiving the LID# low signal, the EC will issue a backlight to close the control signal

30

00:02:56,200 --> 00:03:04,866

Common names for control signals include LCD_BACKOFF, LCD_BLON, etc

31

00:03:09,100 --> 00:03:13,666

When we open the cover, the LID# signal returns to the high state,

32

00:03:15,633 --> 00:03:19,733

and the EC will issue a backlight on signal to turn on the backlight

33

00:03:26,433 --> 00:03:29,400

There is a signal called brightness adjustment,

34

00:03:29,900 --> 00:03:33,266

that is, when we press the keyboard shortcut key,

35

00:03:34,533 --> 00:03:39,266

the EC receives the shortcut key command, through the brightness adjustment signal

36

00:03:39,266 --> 00:03:41,900

to adjust the brightness of the screen backlight

37

00:03:46,300 --> 00:03:49,433

Okay, this is the EC's control of the backlight
