1

00:00:01,433 --> 00:00:05,566

Hello everyone, today let's learn about the EC's management of batteries

2

00:00:10,366 --> 00:00:12,666

This course is divided into two parts,

3

00:00:13,100 --> 00:00:17,333

battery interface signal introduction and battery management by EC

4

00:00:25,400 --> 00:00:29,333

First, let's look at the battery interface pin definition

5

00:00:31,000 --> 00:00:34,066

This BATT+ is the battery power supply

6

00:00:37,666 --> 00:00:43,766

The power supply output and charging voltage input are connected to the battery through these 3 pins

7

00:00:52,566 --> 00:00:59,500

SMB_CLK, SMB_DAT, which is the system management bus clock and data

8

00:01:01,033 --> 00:01:03,866

The two cables are connected to the EC.

9

00:01:04,966 --> 00:01:09,133

The EC obtains the battery power information through the two cables

10

00:01:11,166 --> 00:01:16,533

BATT_PRES#, this is the battery insertion identification signal

11

00:01:19,166 --> 00:01:21,000

When no battery is plugged in,

12

00:01:21,600 --> 00:01:26,300

the signal is pulled up to high by the 3.3V standby power supply

13

00:01:27,266 --> 00:01:31,466

When plugged into the battery, the signal is pulled down to low

14

00:01:32,200 --> 00:01:38,633

A low level indicates that the battery is plugged in, a high level indicates that the battery is not plugged in

15

00:01:39,233 --> 00:01:44,466

These pins are connected to GND, which is the negative terminal of the battery

16

00:01:54,500 --> 00:01:57,733

Let's take a look at the EC's management of the batteries

17

00:01:59,366 --> 00:02:02,766

After the EC detects that the battery is inserted,

18

00:02:04,000 --> 00:02:08,133

it reads the battery power information through the system management bus

19

00:02:11,300 --> 00:02:13,700

If the battery is found to need charging,

20

00:02:14,766 --> 00:02:18,633

it will control the charging circuit through the system management bus

21

00:02:20,766 --> 00:02:24,266

This is the charging chip, and this is the charging inductor

22

00:02:25,733 --> 00:02:29,966

The EC controls the charging circuit to generate the charging voltage

23

00:02:30,100 --> 00:02:32,633

to charge the battery and replenish its energy

24

00:02:42,533 --> 00:02:46,333

If the EC does not recognize that a battery has been inserted,

25

00:02:47,433 --> 00:02:50,833

an icon of the battery is displayed in the system

26

00:02:51,633 --> 00:02:55,300

It is a red cross to indicate that no battery is detected

27

00:02:58,933 --> 00:03:02,166

If the battery is properly inserted and identified,

28

00:03:03,266 --> 00:03:09,266

the battery's power information can be seen in the system and its charging state can be seen

29

00:03:14,733 --> 00:03:17,433

This is the EC's management of the battery
