1

00:00:00,600 --> 00:00:04,000

Hello everyone, today let's learn about the laptop BIOS chip

2

00:00:06,933 --> 00:00:09,500

This course is divided into four parts

3

00:00:10,500 --> 00:00:17,066

common BIOS chip brands, common BIOS chip package forms, BIOS capacity identification,

4

00:00:17,300 --> 00:00:20,666

and the relationship between BIOS, EC and PCH

5

00:00:27,600 --> 00:00:30,400

First let's take a look at the BIOS chip brand

6

00:00:31,400 --> 00:00:40,066

Common brands are: SST, Macronix Electronics, Winbond, cFeon, MSI and Micron

7

00:00:42,566 --> 00:00:49,366

Common packages include SOP 8 pin package, QFN package and BGA package

8

00:00:54,400 --> 00:00:57,900

Only the bottom 8 pins of the BGA package are useful,

9

00:00:59,166 --> 00:01:03,133

which is the same as the pin definition of a normal 8-pin chip

10

00:01:06,400 --> 00:01:10,633

Only the 8 pins on the edges of the QFN package are useful

11

00:01:12,433 --> 00:01:15,000

The bottom part is cooling and grounding

12

00:01:17,066 --> 00:01:19,900

Let's look at its capacity identification

13

00:01:20,400 --> 00:01:23,666

We usually identify the capacity of a chip by its model

14

00:01:25,466 --> 00:01:31,433

For example, "W25Q64" has an actual capacity of 8 megabytes

15

00:01:32,533 --> 00:01:35,700

W refers to the brand of the chip, Winbond,

16

00:01:37,366 --> 00:01:39,900

25 refers to the 25 series

17

00:01:41,933 --> 00:01:45,666

64 is its capacity in bits, which is the Bit width,

18

00:01:51,500 --> 00:01:54,333

and 64 is the 64 Mbits width

19

00:02:00,500 --> 00:02:02,533

A byte requires 8 bits

20

00:02:04,166 --> 00:02:10,733

The 64 Mbits can store only 8 Mbytes of data and 8 Mbytes of BIOS programs

21

00:02:15,966 --> 00:02:18,800

So when we identify the capacity of the BIOS chip,

22

00:02:19,733 --> 00:02:24,066

we divide its mantissa number by 8, which is the actual capacity

23

00:02:26,200 --> 00:02:32,200

For example, this one begins with MX is the BIOS chip of Macronix Electronics

24

00:02:35,000 --> 00:02:37,500

25 indicates the 25 series,

25

00:02:37,900 --> 00:02:43,866

64 indicates the 64 Mbits width, and the actual capacity is 8 Mbytes

26

00:02:46,566 --> 00:02:50,933

This is a BIOS chip from cFeon, 25B256

27

00:02:55,433 --> 00:03:02,933

256 refers to 256 Mbits wide, the actual capacity is 32 Mbytes,

28

00:03:05,700 --> 00:03:08,900

it can store 32 Mbytes BIOS programs

29

00:03:17,266 --> 00:03:23,633

For example, this one is also from Macronix Electronics, and it starts with MX

30

00:03:26,166 --> 00:03:31,166

25 indicates a series of 25 with a mantissa of 128

31

00:03:32,166 --> 00:03:39,100

It indicates that the bit width is 128 Mbits and the actual capacity is 16 Mbytes

32

00:03:43,133 --> 00:03:45,700

This is its capacity identification

33

00:03:48,200 --> 00:03:52,333

Let's take a look at the relationship between BIOS and EC and PCH

34

00:03:53,833 --> 00:03:56,300

Some mainboards have multiple BIOS chips,

35

00:03:56,733 --> 00:04:00,333

of which there are usually two BIOS chips under the bridge,

36

00:04:01,600 --> 00:04:03,700

and their contents are not the same

37

00:04:04,433 --> 00:04:07,366

Each BIOS chip contains different contents

38

00:04:12,800 --> 00:04:16,700

Their internal programs together is a complete BIOS program

39

00:04:17,433 --> 00:04:20,166

When the bridge reads the BIOS chip program,

40

00:04:22,000 --> 00:04:24,300

there are two chip selection signals,

41

00:04:30,366 --> 00:04:37,533

SPI0_CS0# and SPI0_CS1#, which go to the two different BIOS chips

42

00:04:38,466 --> 00:04:45,866

SPI0_MOSI, SPI0_MISO, the data input and output,

43

00:04:46,966 --> 00:04:50,733

and its clock signal, they are shared by the two BIOS

44

00:04:52,333 --> 00:04:57,500

The SPI bus belongs to whoever uses the chip selection signal that has an action

45

00:05:01,900 --> 00:05:06,400

Ok, this is the relationship between BIOS and EC and PCH
