1

00:00:00,200 --> 00:00:03,733

Hello everyone, today we will talk about ACPI advanced power management

2

00:00:05,366 --> 00:00:09,400

ACPI is an advanced configuration and power management port

3

00:00:12,000 --> 00:00:16,800

It is a power management standard developed by Intel, Microsoft and Toshiba

4

00:00:19,100 --> 00:00:23,200

Its function is to control the system into a low-power sleep state,

5

00:00:25,766 --> 00:00:29,300

the purpose is to control the power consumption of the computer

6

00:00:30,566 --> 00:00:34,300

The ACPI controller is integrated inside the chipset

7

00:00:37,600 --> 00:00:42,400

There are two common states: a G state and an S state

8

00:00:44,333 --> 00:00:51,533

When the computer is in normal operation state, it is called S0 state, also called full on state

9

00:00:52,700 --> 00:00:55,333

When the computer is not running any programs,

10

00:00:55,900 --> 00:01:00,466

and after a few minutes, the brightness of the screen decreases,

11

00:01:02,133 --> 00:01:07,766

we call this the CPU idle state, which is the S1 or S2 state

12

00:01:14,100 --> 00:01:18,333

If the CPU is idle, the screen brightness goes dark

13

00:01:21,300 --> 00:01:25,533

If we still haven't run any programs, after a few minutes,

14

00:01:25,900 --> 00:01:30,466

the system will enter S3 state, which is sleep state

15

00:01:36,233 --> 00:01:43,233

In this state, only memory power and standby power are retained, and the screen brightness is black out

16

00:01:46,433 --> 00:01:49,666

In the S3 state, if we want it to wake up,

17

00:01:50,300 --> 00:01:54,333

we just need to move the keyboard or mouse, the screen will light up,

18

00:01:55,033 --> 00:01:57,866

and we can instantly return to the running state

19

00:01:59,100 --> 00:02:04,733

If the system enters S3 state, we still do not have any operation,

20

00:02:05,766 --> 00:02:10,866

after a period of time, the system will enter the sleep state

21

00:02:14,366 --> 00:02:17,566

The S5 state refers to the soft shutdown state,

22

00:02:18,233 --> 00:02:23,433

that is, the shutdown is clicked on the windows operation system

23

00:02:24,366 --> 00:02:31,200

After the system is shut down, we do not pull out the adapter, do not pull out the big battery,

24

00:02:33,266 --> 00:02:37,233

the standby part of the computer power supply still exists,

25

00:02:40,100 --> 00:02:45,000

waiting for boot at any time, this is called soft shutdown state

26

00:02:46,233 --> 00:02:53,033

In the S5 state, both deep sleep standby power and light sleep standby power are available

27

00:02:58,233 --> 00:03:01,800

If it is in battery mode, after the shutdown,

28

00:03:03,266 --> 00:03:05,833

in order to extend the battery life,

29

00:03:08,466 --> 00:03:12,066

the general shutdown will enter a deep sleep state

30

00:03:13,566 --> 00:03:19,266

In the deep sleep state, only the standby power supply in the deep sleep state is retained

31

00:03:19,266 --> 00:03:25,200

to reduce the power consumption in the standby state as much as possible and extend the battery life

32

00:03:29,933 --> 00:03:32,500

If we remove the big battery and the adapter,

33

00:03:33,333 --> 00:03:36,400

all that's left on the mainboard is the button battery

34

00:03:39,333 --> 00:03:43,633

At this time, only the RTC circuit of the mainboard is working

35

00:03:47,466 --> 00:03:52,333

This state is called the physical shutdown state, or G3 state

36

00:03:52,866 --> 00:03:58,833

The signals that control the system entering and exiting these states are called Sleep signals

37

00:04:05,800 --> 00:04:12,533

In the S0 state, these sleep control signals are all invalid and all are high

38

00:04:18,900 --> 00:04:21,633

When SLP_S3# is low,

39

00:04:22,333 --> 00:04:25,966

the system will be controlled to enter S3 state,

40

00:04:26,700 --> 00:04:28,866

and other signals are still high

41

00:04:31,766 --> 00:04:35,900

When SLP_S3# and SLP_S4# are both low,

42

00:04:36,933 --> 00:04:40,233

the system will be controlled to enter S4 state

43

00:04:41,133 --> 00:04:43,133

When SLP_S5# is low,

44

00:04:44,100 --> 00:04:47,966

the system will be controlled to enter the soft shutdown state

45

00:04:53,033 --> 00:04:57,633

In deep sleep, all of these SLP_S*# signals are low

46

00:05:01,400 --> 00:05:04,900

Ok, this is ACPI Advanced Power Management
