Hello, everyone, today we are going to learn the four major working conditions of RTC circuit

2

00:00:07,533 --> 00:00:09,700

This course consists of two parts,

3

00:00:09,800 --> 00:00:15,233

RTC circuit introduction, RTC circuit four major working conditions

4

00:00:18,500 --> 00:00:23,033

First, let's look at a brief introduction to the RTC circuit

5

00:00:27,266 --> 00:00:32,966

RTC is also called real time clock circuit, also can be called CMOS circuit

6

00:00:36,400 --> 00:00:45,066

RTC circuit includes RTC module inside PCH and 32.768KHz clock crystal outside the PCH,

7

00:00:45,800 --> 00:00:49,066

RTC reset circuit and CMOS battery

8

00:00:52,333 --> 00:00:56,666

It is mainly used to store time, date, and ESCD files

9

00:01:00,600 --> 00:01:06,400

The RTC module in PCH mainly includes a real-time clock module and a register,

10

00:01:12,566 --> 00:01:18,133

which is mainly used to ensure the normal operation of time and store CMOS information

11

00:01:18,866 --> 00:01:22,866

Common faults: After the button battery is removed,

12

00:01:23,666 --> 00:01:28,766

information such as the time and date is lost, and BIOS Settings are lost

13

00:01:29,633 --> 00:01:33,300

Because without an adapter and without a large battery,

14

00:01:35,133 --> 00:01:39,300

the only source of power for the RTC circuit is the button battery

15

00:01:42,800 --> 00:01:44,800

If the button battery is removed,

16

00:01:45,100 --> 00:01:47,866

the information stored in it is lost

17

00:01:48,466 --> 00:01:52,833

Next let's look at the RTC circuit four working conditions

18

00:01:53,100 --> 00:01:57,266

In this 100 series chipset standard timing diagram,

19

00:01:59,166 --> 00:02:03,433

the first requirement is to meet the RTC circuit conditions

20

00:02:04,900 --> 00:02:11,966

These several conditions include the RTC circuit of the power supply, VCCRTC

21

00:02:12,633 --> 00:02:15,433

This power supply is provided by the button battery,

22

00:02:15,433 --> 00:02:20,800

or the built-in main battery, and it is a 3.3V high level

23

00:02:24,133 --> 00:02:32,733

RTCR#, SRTCR#, these two are reset signals of RTC circuit, active low level

24

00:02:33,333 --> 00:02:38,033

Strictly speaking, the first is the reset signal of the RTC circuit

25

00:02:38,500 --> 00:02:42,866

and the second is the reset signal of the ME module inside the PCH

26

00:02:45,733 --> 00:02:52,266

The two reset signals in the circuit are supplied by RTC through resistor and capacitor delay

27

00:02:52,633 --> 00:02:57,600

The resistor is usually 20K, the capacitor is 1uF,

28

00:02:57,600 --> 00:03:01,266

and the delay time is usually more than 20 milliseconds

29

00:03:04,433 --> 00:03:09,066

When the chipset is powered, the PCH will power the crystal

30

00:03:11,566 --> 00:03:20,400

The 32.768KHz crystal starts to vibrate, providing the RTC circuit with the reference clock frequency

31

00:03:21,200 --> 00:03:24,733

One power supply, two reset, a clock,

32

00:03:25,600 --> 00:03:29,433

these are the RTC circuit four major working conditions

33

00:03:31,666 --> 00:03:37,266

If any of the conditions is not normal, it will not be able to start up normally
