Hello everyone, today we will talk about light sleep standby conditions

2

00:00:05,833 --> 00:00:09,633

The light sleep standby state is also called the S5 state

3

00:00:12,633 --> 00:00:16,300

First, here are four conditions for light sleep standby

4

00:00:19,833 --> 00:00:22,400

The first is SLP_SUS#,

5

00:00:22,900 --> 00:00:26,700

which is used to turn on and off the main standby power supply

6

00:00:28,766 --> 00:00:34,666

This SLP_SUS# signal is not used when deep sleep is not supported

7

00:00:37,266 --> 00:00:39,300

If deep sleep is supported,

8

00:00:39,500 --> 00:00:46,433

the RTC circuit conditions are normal, and the standby power supply condition in deep sleep is normal

9

00:00:52,533 --> 00:00:55,033

When the chipset detects the adapter,

10

00:00:56,733 --> 00:01:01,600

it sends the SLP_SUS# signal to turn on the main standby power supply

11

00:01:02,333 --> 00:01:10,800

The first is VCCPRIM_3P3, which is the 3.3V standby power supply for PCH

12

00:01:12,066 --> 00:01:19,033

The second is VCCPRIM_1P0, which is the 1.0V primary standby power supply

13

00:01:19,966 --> 00:01:23,266

These are generated by PWM circuit control

14

00:01:24,566 --> 00:01:27,366

After the main standby power supply is normal,

15

00:01:28,000 --> 00:01:35,566

there will be a delay to generate a good signal of the main standby power supply, which is called RSMRST#

16

00:01:36,100 --> 00:01:41,533

This signal is also a reset signal for the ACPI controller inside the PCH

17

00:01:41,966 --> 00:01:46,466

The signal is 3.3V when the main standby power supply is normal

18

00:01:47,566 --> 00:01:51,400

Let's look at the block diagram of the light sleep standby condition

19

00:01:53,566 --> 00:01:58,466

Just now we said that when deep sleep standby conditions are normal,

20

00:01:59,566 --> 00:02:01,733

after detecting the adapter

21

00:02:03,033 --> 00:02:11,666

PCH will issue the SLP_SUS# signal to turn on the PWM circuit and control the 3.3V PWM output

22

00:02:22,533 --> 00:02:29,966

3.3V main standby power supply is provided to the main standby power supply pin of the PCH,

23

00:02:31,466 --> 00:02:36,366

and a good power signal is generated to the RSMRST# pin after a delay

24

00:02:41,266 --> 00:02:50,233

Some circuits will use their PG signal to turn on the next 1.0V standby supply after the 3.3V supply is normal

25

00:02:52,400 --> 00:03:00,000

This 1.0V PWM output will supply power to the VCCPRIM_1P0 pin of the PCH

26

00:03:03,800 --> 00:03:06,966

According to the standard timing diagram of Intel,

27

00:03:08,566 --> 00:03:12,700

the standby conditions of light sleep state include four conditions:

28

00:03:14,200 --> 00:03:20,466

light sleep standby power supply, deep sleep standby power supply, and RTC circuit
