Hello everyone, today we are going to learn about the boot timing sequence

2

00:00:05,566 --> 00:00:07,933

This lesson includes two aspects,

3

00:00:08,766 --> 00:00:11,933

one is the explanation of the boot timing signal,

4

00:00:12,533 --> 00:00:15,366

the other is the introduction of boot process

5

00:00:16,133 --> 00:00:20,400

First, let's look at the boot timing signal explanation

6

00:00:22,800 --> 00:00:25,700

When the previous standby conditions are normal,

7

00:00:26,166 --> 00:00:30,166

after receiving this PWRBTN# trigger signal,

8

00:00:31,300 --> 00:00:43,166

the PCH of the 100 series chipset will pull up the following signals to high level, SLP_S5#, SLP_S4#, SLP_S3#, etc.

9

00:00:50,166 --> 00:00:54,066

SLP_S5# indicates to exit the shutdown state

10

00:00:55,866 --> 00:01:02,566

SLP_S4# is used to enable power supply for S3 state, such as memory power supply

11

00:01:05,933 --> 00:01:11,166

SLP_S3# will be used to enable the power supply required by the S0 state,

12

00:01:11,366 --> 00:01:15,633

such as bus power supply, CPU power supply, etc

13

00:01:16,233 --> 00:01:23,733

In the 100 series chipset, this SLP_A# is no longer used because the ME module is powered off

14

00:01:24,300 --> 00:01:29,500

Once this SLP_A# was used to turn on the power supply of the ME module

15

00:01:29,800 --> 00:01:32,500

Now there is no need for it to exist,

16

00:01:33,966 --> 00:01:39,366

since the ME module power supply has been removed from the 100 series chipset

17

00:01:40,866 --> 00:01:48,400

SLP_LAN# and SLP_WLAN# are used to enable the power supply of the network adapter

18

00:01:49,633 --> 00:01:54,533

This signal is used only when some Intel original NICs are used

19

00:01:56,466 --> 00:01:59,866

In most models, these two signals are not used

20

00:02:02,166 --> 00:02:07,633

SLP_S0#, this signal is not present in the standard timing diagram,

21

00:02:08,200 --> 00:02:10,833

but it is present in the actual circuit

22

00:02:11,433 --> 00:02:18,466

This signal is used to control the CPU power supply into light load mode when the PCH and CPU are idle

23

00:02:19,633 --> 00:02:25,066

This signal can also be connected to the EC for other power management purposes

24

00:02:29,066 --> 00:02:31,166

Now let's look at the boot process

25

00:02:32,766 --> 00:02:37,700

For a computer to be turned on, the EC and PCH must be involved

26

00:02:39,266 --> 00:02:47,133

In the first step, the EC must meet standby power supply, standby clock, and standby reset requirements

27

00:02:47,833 --> 00:02:54,100

The EC program is read, the pin is configured, and the adapter is detected

28

00:02:55,666 --> 00:03:01,266

The LID# signal is high level, and the switching signal is also high level

29

00:03:01,600 --> 00:03:03,900

If these conditions are satisfied,

30

00:03:04,666 --> 00:03:09,500

we press the switch, it will generate a high- low- high level jump

31

00:03:10,566 --> 00:03:15,400

That is, when we press the switch, the signal will be pulled down,

32

00:03:17,100 --> 00:03:21,100

and when we release the switch it will return to the high level

33

00:03:21,666 --> 00:03:23,833

After receiving the switching signal,

34

00:03:24,400 --> 00:03:29,266

the EC will delay sending out a high- low- high pulse to the PCH pin

35

00:03:29,966 --> 00:03:37,166

When all the 10 standby conditions of PCH are normal, these include the top 4 standby conditions of RTC,

36

00:03:38,166 --> 00:03:44,066

as well as the deep sleep standby condition and the light sleep standby condition

37

00:03:44,700 --> 00:03:50,900

The PCH sends out the SLP_S*# signal to turn on the power supply of the following power supply

38

00:03:51,666 --> 00:03:53,700

Ok, this is the boot process
