Hello everyone, today let's learn about the timing of each power supply

2

00:00:07,133 --> 00:00:09,333

This course consists of two parts

3

00:00:11,666 --> 00:00:15,066

One is the explanation of each power supply signal,

4

00:00:15,600 --> 00:00:18,600

and the other is the timing of each power supply signal

5

00:00:23,400 --> 00:00:26,733

In this timing diagram for the 100 series chipset

6

00:00:27,000 --> 00:00:32,633

After the previous standby conditions are normal, and PCH received the switch signal

7

00:00:33,566 --> 00:00:38,666

It sends out various SLP_S*# signals to turn on each power supply

8

00:00:39,333 --> 00:00:42,733

These are the voltages that are involved in the power supply

9

00:00:43,033 --> 00:00:46,733

The first VDIMM is the power supply for the memory

10

00:00:47,500 --> 00:00:55,533

These include 1.2V of main supply for the memory VDDQ, and 2.5V of its VPP supply

11

00:00:57,766 --> 00:01:06,300

There are also some secondary voltages over 1.2V, such as VCCPLL_OC power supply and so on

12

00:01:07,400 --> 00:01:14,533

This power supply is generally controlled by the SLP_S4# or SLP_S5# signals sent above

13

00:01:16,733 --> 00:01:27,066

This VCC refers to the secondary voltage 3.3V, secondary voltage 5V, and secondary voltage 1.0V, etc.,

14

00:01:37,566 --> 00:01:47,033

including bus power supply VCCIO, VCCST, VCCSTG, VCCPLL, etc

15

00:01:49,266 --> 00:01:54,500

These supplies are usually controlled by SLP_S3# signals from the front

16

00:02:02,933 --> 00:02:05,300

When these power supplies are normal,

17

00:02:05,766 --> 00:02:14,700

a signal VCCST_PWRGD is generated and sent to the CPU to inform the CPU that the vccst power supply is normal

18

00:02:20,333 --> 00:02:22,966

This PG signal is usually 1V

19

00:02:24,266 --> 00:02:32,933

The CPU will delay sending a DDR_VTT_CNTL signal to control the power supply of the memory bus to 0.6V,

20

00:02:36,233 --> 00:02:39,033

which is half of the main power supply of the memory

21

00:02:43,233 --> 00:02:48,933

It also controls the generation of VCCSA and VCCCORE_CPU

22

00:02:51,466 --> 00:02:54,066

These are all power supplies to the CPU

23

00:02:54,800 --> 00:03:02,066

Where VCCSA is the system butler power supply to the CPU, 1.0V or 1.05V

24

00:03:03,033 --> 00:03:09,333

VCCCORE_CPU Indicates the power supply to the CPU core, which is about 1V

25

00:03:11,566 --> 00:03:15,200

These are usually controlled after the bus is powered properly

26

00:03:18,033 --> 00:03:24,233

This VBOOT voltage refers to the boot voltage, which is often referred to as the boot supply

27

00:03:25,433 --> 00:03:27,933

It means that the CPU is not working yet,

28

00:03:28,800 --> 00:03:32,166

so give it a power supply in advance as a starting voltage

29

00:03:35,133 --> 00:03:38,866

Well, here's the explanation for the terms of each power supply

30

00:03:39,866 --> 00:03:43,100

Now let's look at the timing of their generations

31

00:03:46,666 --> 00:03:53,200

First, after the standby condition is normal, the PCH receives the switch signal

32

00:03:53,566 --> 00:03:59,833

It will issue signals SLP S5#, SLP S4#, SLP S3#

33

00:04:01,133 --> 00:04:06,200

The power supply is switched on by the EC or SLP_S*# signals directly

34

00:04:11,666 --> 00:04:16,266

SLP_S4# or SLP_S5# will be enabled through the EC

35

00:04:16,266 --> 00:04:23,133

or directly to supply 1.2V of memory power and 2.5V of VPP of memory power

36

00:04:29,566 --> 00:04:34,500

SLP_S3# will turn on these secondary voltage 3.3V,

37

00:04:34,866 --> 00:04:43,233

secondary voltage 5V, VCCST/ VCCSTG directly or indirectly through EC

38

00:04:52,466 --> 00:04:59,066

When the power supply is normal, a VCCST_PWRGD signal will be generated to the CPU

39

00:05:01,133 --> 00:05:09,833

The CPU will delay sending a DDR_VTT_CNTL signal to enable 0.6V VTT power supply for the memory

40

00:05:11,666 --> 00:05:16,166

At the same time, when VCCST_PWRGD is normal,

41

00:05:16,566 --> 00:05:22,300

it will generate a CPU power supply start signal through EC or other circuit conversion

42

00:05:22,566 --> 00:05:28,966

to turn on the CPU core power supply VBOOT voltage and VCCSA power supply

43

00:05:32,600 --> 00:05:35,966

Ok, this is the timing generation of each power supply
