Hello everyone, today we are going to learn the timing sequence of PG signal and clock signal generation

2

00:00:09,966 --> 00:00:13,566

First, after all the previous power supplies are normal

3

00:00:14,400 --> 00:00:21,400

PCH must receive a good power supply signal, PCH_PWROK, 3.3V

4

00:00:22,866 --> 00:00:28,466

This signal is generated after the preceding power supply is normal and sent to PCH,

5

00:00:30,033 --> 00:00:33,466

which indicates that S0 state voltage is normal

6

00:00:35,633 --> 00:00:41,266

If the signal is abnormal, power failure and power-on failure will occur

7

00:00:44,566 --> 00:00:51,866

After the power supply is normal, the 24MHz crystal oscillator of the PCH will start to vibrate and work,

8

00:00:52,966 --> 00:00:57,033

providing the reference frequency to the clock module inside the PCH

9

00:00:59,666 --> 00:01:08,066

Next, after PCH gets the signal PCH_PWROK, it reads the ME firmware program in the BIOS,

10

00:01:08,333 --> 00:01:13,466

configures its internal pins, and initializes the clock module

11

00:01:16,500 --> 00:01:22,000

After the initialization is complete, the system outputs all clocks,

12

00:01:23,066 --> 00:01:27,300

including the LPC bus clock and PCIE bus clock

13

00:01:30,300 --> 00:01:36,433

The PCH then sends a PG signal to the CPU, PROCPWRGD

14

00:01:40,533 --> 00:01:46,166

This is for the CPU, indicating that the power supply to the CPU core is normal

15

00:01:47,933 --> 00:01:52,366

The PCH receives a delayed signal, SYS_PWROK,

16

00:01:53,066 --> 00:01:55,833

indicating that the system power supply is normal

17

00:01:56,833 --> 00:02:01,733

This is a key PG signal used as the next step to generate the reset signal

18

00:02:04,633 --> 00:02:07,733

Ok, that's the timing of the PG clock signal
