126. Reset signal and integrated GPU power timing
In this lesson, we will learn the timing sequence generation of reset signal and integrated graphics card power supply.
Detail
Comments

1

00:00:00,566 --> 00:00:02,500

Hello everyone, in this lesson,

2

00:00:02,600 --> 00:00:08,533

we will learn the timing sequence generation of reset signal and integrated graphics card power supply

3

00:00:09,666 --> 00:00:11,800

This lesson consists of two parts

4

00:00:14,700 --> 00:00:20,766

First, the reset signal and the integrated graphics card power supply timing sequence generation

5

00:00:22,600 --> 00:00:26,300

Second, the distribution of reset signals

6

00:00:27,533 --> 00:00:33,466

First, let's look at the timing of the reset signal and the integrated graphics card power supply

7

00:00:34,433 --> 00:00:37,400

Let's look at the explanation of these signals

8

00:00:38,366 --> 00:00:40,866

The first one is called Platform reset,

9

00:00:41,133 --> 00:00:45,133

abbreviated PLTR #, 3.3V

10

00:00:46,633 --> 00:00:50,600

This signal is usually given to each chip and slot as a reset

11

00:00:51,900 --> 00:00:59,233

For example, the LPC bus to network card, WIFI, independent graphics card and EC

12

00:01:03,900 --> 00:01:06,266

When the platform reset is normally,

13

00:01:06,866 --> 00:01:12,433

the CPU also receives the power good signal PROCPWRGD

14

00:01:12,700 --> 00:01:16,533

and it will send the SVID signal to the CPU power supply chip

15

00:01:16,533 --> 00:01:19,866

to control and adjust the CPU core power supply

16

00:01:23,166 --> 00:01:27,766

This VCCCORE_CPU is the adjusted core power supply

17

00:01:31,333 --> 00:01:33,933

Once the CPU is powered and reset,

18

00:01:35,700 --> 00:01:39,900

it starts to issue addressing instructions to find the BIOS address

19

00:01:42,433 --> 00:01:47,833

It will send this address finding instruction through the DMI bus to PCH,

20

00:01:48,433 --> 00:01:52,000

PCH through the SPI bus to read the BIOS program,

21

00:01:54,133 --> 00:01:57,566

and begin to self-check the entire mainboard circuit

22

00:01:58,700 --> 00:02:02,100

During the self-test, when the memory is detected,

23

00:02:03,866 --> 00:02:09,433

PCH will send a memory reset signal, DRAM_RESET#

24

00:02:14,266 --> 00:02:16,400

After self-checking the memory,

25

00:02:18,333 --> 00:02:26,333

the CPU will send out SVID signal to control the generation of integrated display power supply, VCCGT

26

00:02:28,333 --> 00:02:32,466

Next, let's look at the distribution of reset signals

27

00:02:34,033 --> 00:02:39,766

In fact, when the platform reset is issued, the CPU reset is also issued

28

00:02:40,133 --> 00:02:47,833

Platform reset is called PLTRST#, and it is given to network card, EC, graphics card,

29

00:02:47,933 --> 00:02:51,900

and various slots, mainly for external devices

30

00:02:53,233 --> 00:02:59,966

The CPU reset is called PLTRST_CPU#, or PLTRST_PROC#

31

00:03:01,866 --> 00:03:06,733

and is a separate reset signal sent to the CPU to initialize it

32

00:03:12,566 --> 00:03:14,466

Another is memory reset

33

00:03:15,233 --> 00:03:22,333

It is sent to the memory slot by the PCH when the self-check memory is found during the startup self-check

34

00:03:25,366 --> 00:03:32,933

In this distribution, we can see that the platform reset is given to the graphics card, network card,

35

00:03:33,366 --> 00:03:38,900

M.2 interface, EC, and DEBUG chips and slots

36

00:03:42,233 --> 00:03:45,700

The CPU reset signal is only given to the CPU,

37

00:03:46,566 --> 00:03:49,700

and the memory reset signal is only given to the memory

38

00:03:51,233 --> 00:03:54,300

Okay, this is the reset signal distribution
