1

00:00:02,666 --> 00:00:06,500

Now I'll introduce another rotary-air hot gun for you

2

00:00:09,000 --> 00:00:11,233

First let's learn how to use it

3

00:00:11,333 --> 00:00:12,600

Turn it on

4

00:00:17,166 --> 00:00:20,200

Two round buttons with arrows on the right

5

00:00:21,133 --> 00:00:23,066

They're for temperature

6

00:00:24,266 --> 00:00:26,400

Up for increasing temperature

7

00:00:30,266 --> 00:00:32,600

Down for decreasing temperature

8

00:00:39,200 --> 00:00:40,933

When adjusting the temperature

9

00:00:41,000 --> 00:00:44,633

This large number on the LCD will change

10

00:00:47,400 --> 00:00:51,000

The left knob is for the air volume adjustment

11

00:00:53,766 --> 00:00:56,566

Turn counterclockwise to decrease

12

00:00:56,866 --> 00:01:01,833

Rotate clockwise to increase, it will be displayed in this area

13

00:01:05,200 --> 00:01:08,000

After everything is all set

14

00:01:08,266 --> 00:01:11,566

You can save the current setting with this button

15

00:01:12,166 --> 00:01:15,500

Long press any of these buttons

16

00:01:21,933 --> 00:01:23,966

The machine beeps

17

00:01:24,266 --> 00:01:28,400

This means that the temperature has been saved in the corresponding setting

18

00:01:28,500 --> 00:01:30,300

Reset temperature

19

00:01:30,366 --> 00:01:31,400

Set air volume

20

00:01:31,400 --> 00:01:34,466

It can be saved in the second and third settings

21

00:01:35,933 --> 00:01:37,800

After the temperature is set

22

00:01:39,366 --> 00:01:40,800

Pick up the handle

23

00:01:43,166 --> 00:01:44,933

Start to heat

24

00:01:47,733 --> 00:01:51,533

Temperature and air volume reach our set values

25

00:01:51,600 --> 00:01:54,633

It's in a constant temperature state

26

00:01:55,133 --> 00:01:57,133

You can weld now

27

00:01:57,800 --> 00:01:58,800

Welded

28

00:01:59,300 --> 00:02:01,600

Put the handle back onto the holder

29

00:02:03,200 --> 00:02:05,333

Temperature starts to drop

30

00:02:06,600 --> 00:02:08,866

When it drops to 100 degrees

31

00:02:08,866 --> 00:02:11,000

It'll be in standby

32

00:02:13,766 --> 00:02:17,100

Next, let's learn how to replace the nozzle

33

00:02:23,533 --> 00:02:25,400

When in standby

34

00:02:25,833 --> 00:02:27,366

Turn it off

35

00:02:27,866 --> 00:02:29,233

Pick up the handle

36

00:02:29,333 --> 00:02:33,600

This hot air gun comes with a special nozzle removal wrench

37

00:02:34,733 --> 00:02:38,266

There is a raised metal at the position of the nozzle

38

00:02:40,500 --> 00:02:43,233

There is also one on the opposite side

39

00:02:44,266 --> 00:02:47,533

There are two notches on both sides of the wrench

40

00:02:47,566 --> 00:02:49,933

Fit the notch to the raised metal position

41

00:02:52,166 --> 00:02:53,533

Twist the nozzle

42

00:02:57,033 --> 00:02:58,600

Then remove the nozzle

43

00:03:01,966 --> 00:03:03,833

Find a suitable nozzle

44

00:03:04,666 --> 00:03:07,933

There will be a raised metal on the edge of the nozzle

45

00:03:08,433 --> 00:03:10,566

Correspondingly

46

00:03:11,533 --> 00:03:15,033

Put it back in the position of this notch of the duct

47

00:03:18,466 --> 00:03:19,500

Press tightly

48

00:03:21,966 --> 00:03:26,300

Because it has just been heated, the nozzle is not easy to replace

49

00:03:31,033 --> 00:03:33,100

After getting stuck

50

00:03:34,433 --> 00:03:35,733

Turn the wrench

51

00:03:36,233 --> 00:03:37,300

Pull out the wrench

52

00:03:39,500 --> 00:03:41,500

Replacement completed
