1

00:00:02,133 --> 00:00:07,133

Today I'll introduce a consumable used in repairing electronic products

2

00:00:07,466 --> 00:00:08,633

Solder paste

3

00:00:09,333 --> 00:00:12,066

Two solder pastes commonly used in maintenance

4

00:00:12,400 --> 00:00:18,400

One is a medium temperature solder paste with a melting point of 183 degrees Celsius

5

00:00:18,566 --> 00:00:24,700

The other one is a low temperature solder paste with a melting point of 138 degrees Celsius

6

00:00:28,033 --> 00:00:32,633

Medium temperature solder paste is mainly used for chip reballing

7

00:00:36,866 --> 00:00:39,766

This is a chip removed from the motherboard

8

00:00:41,066 --> 00:00:43,800

If you wanna solder back to the original motherboard

9

00:00:44,066 --> 00:00:46,400

Or solder it to another motherboard

10

00:00:47,366 --> 00:00:50,633

All solder joints of the chip need to be reballed

11

00:00:53,000 --> 00:01:01,866

The 138-degree solder paste is mainly used for the residual solder treatment on the circuit board after the chip is disassembled

12

00:01:02,666 --> 00:01:10,800

Now, you can use low-temperature solder first to cool the residual solder on the motherboard

13

00:01:11,300 --> 00:01:14,200

We'll deal with it after it cools down

14

00:01:14,300 --> 00:01:16,466

This will lower the temperature

15

00:01:17,400 --> 00:01:19,233

It'll be easier to deal

16

00:01:21,100 --> 00:01:28,600

Low temperature solder paste can also be used to solder the frame of some early double-layer motherboards of iPhone

17

00:01:29,733 --> 00:01:33,833

The double-layer motherboard adopts the superposition of two motherboards

18

00:01:34,466 --> 00:01:41,066

The upper motherboard and the lower motherboard have a lot of signals or power supplies that need to be connected together

19

00:01:42,600 --> 00:01:44,733

iPhone models before iPhone 12

20

00:01:44,766 --> 00:01:51,100

The solder joints on the edge of the superimposed double-layer motherboard are all soldered with low temperature solder

21

00:01:51,533 --> 00:01:53,033

After iPhone 12

22

00:01:53,900 --> 00:01:57,666

These solder joints on the edge are welded with medium temperature solder

23

00:01:59,033 --> 00:02:01,800

We should pay attention when buying solder paste

24

00:02:03,733 --> 00:02:04,566

First

25

00:02:05,833 --> 00:02:11,166

You can check if there is a lot of solder oil residue on the edge of the solder paste

26

00:02:14,533 --> 00:02:19,566

If the storage time is particularly long or the storage conditions are not correct

27

00:02:21,033 --> 00:02:24,533

Soldering oil inside the solder paste will seep out

28

00:02:25,300 --> 00:02:28,933

This indicates that the solder paste has deteriorated

29

00:02:29,133 --> 00:02:30,166

Not available

30

00:02:30,700 --> 00:02:38,133

In addition, we can check whether the solder powder of the solder paste has any signs of dullness and blackness

31

00:02:42,533 --> 00:02:44,533

If you have a microscope

32

00:02:45,000 --> 00:02:47,266

We can pick out some of the solder paste

33

00:02:48,433 --> 00:02:50,300

smear on paper towel

34

00:02:50,766 --> 00:02:52,300

or wthite paper

35

00:02:53,833 --> 00:02:55,666

observe with microscope

36

00:02:56,500 --> 00:03:00,400

Is there any impurities in the solder powder of the solder paste?

37

00:03:01,700 --> 00:03:05,633

Also, is the size of the solder powder particles uniform?

38

00:03:05,866 --> 00:03:12,533

Then you can also check whether there are signs of blackening and oxidation on the surface of the solder powder

39

00:03:13,566 --> 00:03:18,433

These are the methods we use to see if a bottle of solder paste is good or not

40

00:03:20,000 --> 00:03:24,766

Then when using solder paste, take out the solder paste that needs to be used

41

00:03:28,000 --> 00:03:29,466

Quickly tighten the cap

42

00:03:30,933 --> 00:03:34,333

Do not expose the solder paste to the air for a long time

43

00:03:35,100 --> 00:03:38,633

Otherwise,the solder paste can easily deteriorate

44

00:03:38,966 --> 00:03:42,666

For long-term unused solder paste or there is too much stock

45

00:03:45,333 --> 00:03:49,200

You can store them in the freezer compartment of the refrigerator

46

00:03:49,966 --> 00:03:53,433

The temperature should better be below 20 degrees Celsius

47

00:03:53,600 --> 00:03:56,033

It can be stored for a long time

48

00:03:56,400 --> 00:03:59,733

So much for solder paste today,thank you for watching
