1

00:00:03,666 --> 00:00:09,666

Today I'll introduce a consumable used in the maintenance of an electronic product

2

00:00:09,966 --> 00:00:11,733

Enamelled wire

3

00:00:11,866 --> 00:00:14,100

We also call it varnished wire

4

00:00:14,400 --> 00:00:21,000

The enamelled wire means that the surface of the copper wire is covered with a layer of insulating paint

5

00:00:21,566 --> 00:00:24,266

So that's why we call it enamelled wire

6

00:00:25,600 --> 00:00:29,733

The enamelled wire we commonly use has two specifications

7

00:00:29,900 --> 00:00:33,200

One is the wire diameter of 0.1 mm

8

00:00:33,300 --> 00:00:37,600

The other is a wire diameter of 0.01 mm

9

00:00:37,766 --> 00:00:41,300

The one on the left has a slightly thicker copper wire

10

00:00:41,800 --> 00:00:43,800

It's 0.1 mm

11

00:00:44,300 --> 00:00:49,766

The transparent large roll on the right side, the copper wire is thinner relatively

12

00:00:50,733 --> 00:00:53,133

It's 0.01 mm

13

00:00:53,333 --> 00:00:55,500

When would enamelled wire be used?

14

00:00:55,766 --> 00:01:00,800

It is mainly used for some line disconnections when we repair the motherboard

15

00:01:02,233 --> 00:01:04,133

Let's say I now have this board

16

00:01:06,033 --> 00:01:10,566

We found from the maintenance drawings that from this point to this point is connected

17

00:01:12,266 --> 00:01:18,366

But now when I use a multimeter to measure, I find that these two points are not connected

18

00:01:18,700 --> 00:01:22,800

If you want to fix this fault, you may need to replace the motherboard

19

00:01:23,066 --> 00:01:24,600

But it'll cost a lot

20

00:01:26,166 --> 00:01:29,800

We can use copper wire to reconnect the two points together

21

00:01:30,566 --> 00:01:34,433

This is where the insulating layer on the surface comes into play

22

00:01:35,666 --> 00:01:38,366

Copper wire is a conductive object

23

00:01:39,833 --> 00:01:50,533

After the line is connected, the copper wire may be connected with other components in the area passing through the circuit board, resulting in a short circuit

24

00:01:51,033 --> 00:01:54,133

Because there is an insulating layer on the surface

25

00:01:57,200 --> 00:01:59,833

it will not be connected to other components

26

00:02:00,533 --> 00:02:03,833

Just simply turn on the line it is connected to

27

00:02:07,900 --> 00:02:11,466

The thick one is 0.1 mm in diameter

28

00:02:12,666 --> 00:02:15,266

This can be connected to some power lines

29

00:02:20,366 --> 00:02:23,300

The thin one is 0.01mm

30

00:02:24,000 --> 00:02:26,966

This can be connected to some signal control circuit

31

00:02:28,500 --> 00:02:30,500

or signal transmission circuit

32

00:02:31,400 --> 00:02:34,366

So much for this,thank you for watching
