1

00:00:02,000 --> 00:00:08,400

Today I will introduce a consumable used in the repair of an electronic product

2

00:00:09,666 --> 00:00:10,666

Desoldering wick

3

00:00:12,066 --> 00:00:13,300

Just like the name

4

00:00:13,733 --> 00:00:17,533

It is a kind of wire that can absorb solder

5

00:00:17,700 --> 00:00:22,600

There are many kinds of specifications of different widths in the market

6

00:00:23,866 --> 00:00:27,800

The width of the copper sheet has different specifications

7

00:00:29,233 --> 00:00:33,733

There are two specifications of the desoldering wick we commonly use

8

00:00:33,933 --> 00:00:36,900

The left one is 3.5 mm

9

00:00:37,333 --> 00:00:40,233

The right one is 2.0 mm

10

00:00:42,166 --> 00:00:49,500

3.5 mm is mainly used to repair large size circuits such as notebooks

11

00:00:50,033 --> 00:00:55,366

2 mm is mainly used for repairing small size circuits such as mobile phones

12

00:00:56,033 --> 00:00:59,133

Let's learn about the use of desoldering wick

13

00:01:02,333 --> 00:01:05,200

Here is a motherboard with the chip removed

14

00:01:06,900 --> 00:01:09,733

The chip is relatively large

15

00:01:11,800 --> 00:01:16,466

Now,you can use the wide desoldering wick for repairing the notebook

16

00:01:17,600 --> 00:01:23,600

Put the desoldering wick on top of the motherboard solder joints where the chip was removed

17

00:01:24,866 --> 00:01:27,700

Heat the desoldering wick with a soldering iron

18

00:01:28,200 --> 00:01:30,833

Let the solder on the motherboard melt

19

00:01:31,166 --> 00:01:34,666

The copper wire absorbs the solder remaining on the motherboard

20

00:01:35,033 --> 00:01:37,800

Keep the solder joint in a flat state

21

00:01:39,200 --> 00:01:40,466

If the chip size is relatively small

22

00:01:42,333 --> 00:01:43,866

like this

23

00:01:45,200 --> 00:01:49,666

This chip is already smaller than the width of the desoldering wick

24

00:01:49,766 --> 00:01:52,566

You won't be able to put it on the motherboard

25

00:01:52,900 --> 00:01:55,700

We can use narrow desoldeirng wick

26

00:01:56,333 --> 00:01:58,266

It's easy to operate

27

00:02:00,566 --> 00:02:01,800

Even smaller size

28

00:02:02,900 --> 00:02:05,033

We can use narrower desoldering wick

29

00:02:06,066 --> 00:02:11,766

The 2.0mm specification is basically universal when repairing mobile phones

30

00:02:12,000 --> 00:02:14,000

If the chip size is smaller

31

00:02:14,033 --> 00:02:16,333

We can cut the desoldering wick narrow

32

00:02:16,833 --> 00:02:20,000

Make it fit into a smaller operating space

33

00:02:20,200 --> 00:02:22,466

This is how to use desoldering wick

34

00:02:23,566 --> 00:02:26,933

Let's talk about some precautions when buying desoldering wick

35

00:02:27,500 --> 00:02:29,366

When shopping for desoldering wick

36

00:02:29,733 --> 00:02:34,366

First we gotta check whether the copper wire of the desoldering wick is bright

37

00:02:36,700 --> 00:02:40,200

Whether there are signs of oxidation and blackening

38

00:02:40,766 --> 00:02:41,666

Like this

39

00:02:43,933 --> 00:02:47,100

Obviously the top one is darker than the bottom one

40

00:02:47,666 --> 00:02:50,533

First, observe the copper wire finish

41

00:02:50,633 --> 00:02:54,666

Second, observe the density of copper wire weaving

42

00:02:54,700 --> 00:02:56,233

Are there any gaps

43

00:02:56,533 --> 00:02:58,700

Or there is a little mess when weaving

44

00:02:59,100 --> 00:03:04,266

The last one is to see if there will be some flux material in this desoldering wick

45

00:03:04,433 --> 00:03:08,933

It's narrow, it may not be clear without a microscope

46

00:03:10,166 --> 00:03:12,100

Let's take a look at this wide one

47

00:03:13,533 --> 00:03:15,500

Pull back and forth a few times

48

00:03:17,266 --> 00:03:19,266

Eventually you will find

49

00:03:20,300 --> 00:03:23,066

There are some white powder in the copper wire

50

00:03:24,333 --> 00:03:28,433

This one is soaked in rosin after weaving desoldering wick

51

00:03:28,466 --> 00:03:34,033

In this way, the surface of each copper wire will be covered with a layer of rosin

52

00:03:34,566 --> 00:03:40,566

In this way,the desoldering wick is not easy to oxidize

53

00:03:40,800 --> 00:03:42,433

When desoldering

54

00:03:44,033 --> 00:03:47,766

Because it has rosin, it will be smoother when desoldering

55

00:03:48,000 --> 00:03:51,933

These are the a few things to keep in mind when buying desoldering wick

56

00:03:52,100 --> 00:03:56,000

So much for desoldering wick today.Thank you for watching
