1

00:00:03,033 --> 00:00:08,266

Today, I'll introduce a tool used in the repair of electronic products

2

00:00:09,300 --> 00:00:11,500

Thermal insulation silicone pad

3

00:00:12,833 --> 00:00:16,200

You can see two thermal insulation silicone pads

4

00:00:16,666 --> 00:00:22,633

This large blue size has a lot of slots and holes already made when it leaves the factory

5

00:00:24,066 --> 00:00:27,500

This silicone pad is a standard maintenance work pad

6

00:00:28,000 --> 00:00:30,233

It can be used to place tools

7

00:00:30,600 --> 00:00:32,766

And as for this silicone pad

8

00:00:33,833 --> 00:00:36,000

There are some holes for screws

9

00:00:36,333 --> 00:00:39,700

For example, after we disassemble a mobile phone

10

00:00:39,800 --> 00:00:44,566

The screws can be placed in this hole according to the layout of the phone

11

00:00:44,800 --> 00:00:52,266

When installing back to the phone, you can determine where the screws are to be installed based on the approximate area

12

00:00:54,066 --> 00:00:58,266

There are also some areas with magnets on the edge of this silicone pad

13

00:00:58,600 --> 00:01:01,233

This area has already added magnets

14

00:01:01,433 --> 00:01:04,133

The screwdriver will be attached to this area

15

00:01:04,600 --> 00:01:05,933

And as for this area

16

00:01:07,166 --> 00:01:11,366

Some of the screws we removed can be placed in this magnetic area

17

00:01:11,566 --> 00:01:17,333

When shaking the table or the silicone pad, the screws are not easy to fall off because of the magnet

18

00:01:17,566 --> 00:01:21,366

Then let's take a look at the small size silicone pad in the middle

19

00:01:21,533 --> 00:01:28,400

This silicone pad is mainly suitable for some maintenance staff with relatively small operating space

20

00:01:28,666 --> 00:01:34,800

It also has the characteristics of high temperature resistance and corrosion resistance

21

00:01:35,200 --> 00:01:41,333

Silicone pads can basically withstand temperatures around 300 degrees without melting

22

00:01:41,533 --> 00:01:48,133

When we use some strong corrosive liquids like PCB cleaner.The surface is not easily corroded

23

00:01:48,933 --> 00:01:53,166

If soldering directly on the desktop when repairing the motherboard

24

00:01:53,466 --> 00:01:57,800

It may damage the original silicone pad of our desktop

25

00:01:58,633 --> 00:02:05,433

When cleaning the board on the desktop, the PCB cleaner may corrode the surface of the rubber blanket

26

00:02:06,400 --> 00:02:11,500

So we recommend using this silicone pad for thermal insulation and anti-corrosion

27

00:02:12,033 --> 00:02:16,600

That's all about the thermal insulation sillicone pad.Thank you for watching
