1

00:00:00,366 --> 00:00:03,033

This is an universal solder fixture

2

00:00:03,466 --> 00:00:06,366

Mainly used to repair some Android motherboards

3

00:00:06,666 --> 00:00:11,466

It uses this kind of screw to push the slider forward and backward

4

00:00:11,566 --> 00:00:15,866

We put the motherboard that needs to be soldered into this area in the middle

5

00:00:16,566 --> 00:00:19,166

This is an Android motherboard

6

00:00:21,500 --> 00:00:27,366

When the screw drives the slider to move to the right, it can reach this area of the motherboard

7

00:00:27,866 --> 00:00:29,866

So the motherboard is fixed

8

00:00:31,266 --> 00:00:33,533

This fixture is for Android

9

00:00:33,766 --> 00:00:38,133

Android motherboard does not have this kind of special fixture

10

00:00:38,966 --> 00:00:42,633

And Android motherboards come in a variety of shapes

11

00:00:43,333 --> 00:00:44,666

They could be very different

12

00:00:45,600 --> 00:00:48,400

So we can use this universal fixture to fix

13

00:00:49,333 --> 00:00:54,300

The advantage of this universal fixture is that it supports a variety of models

14

00:00:54,766 --> 00:00:56,733

But there are also disadvantages

15

00:00:57,066 --> 00:01:00,433

The disadvantage is that it is not so stable

16

00:01:00,533 --> 00:01:03,033

And there are very few points of support

17

00:01:03,900 --> 00:01:08,300

There are some places like this one on the right side of the board we have now

18

00:01:08,666 --> 00:01:11,533

Just clamped this tiny bit of area

19

00:01:11,733 --> 00:01:13,600

This area is not clamped

20

00:01:14,233 --> 00:01:18,933

If the clamp is too tight, this area of the motherboard may be deformed

21

00:01:19,333 --> 00:01:20,300

If too loose

22

00:01:20,533 --> 00:01:26,500

When this board is soldered, it is very likely that the chip will fall off if you pick it up a little

23

00:01:26,533 --> 00:01:29,600

So we only use it without a dedicated fixture

24

00:01:30,100 --> 00:01:36,133

Anyway,using this kind of fixture is relatively safer than doing the disassembly on the table

25

00:01:37,066 --> 00:01:39,900

This is one of the universal solder fixtures

26

00:01:40,233 --> 00:01:45,433

Which is to use this kind of screw adjust the slider to move left and right to fix the motherboard

27

00:01:46,100 --> 00:01:47,300

There is another kind

28

00:01:48,133 --> 00:01:51,500

It also has chip slots on the left and right sides

29

00:01:51,833 --> 00:01:55,733

In the middle, three sliders are used to fix the motherboard

30

00:01:56,200 --> 00:01:58,433

The two sliders above are movable

31

00:02:00,000 --> 00:02:03,400

The area below can also be pushed back and forth

32

00:02:03,900 --> 00:02:06,400

And this buckle has a spring at the bottom

33

00:02:07,966 --> 00:02:10,433

To use elastic pressure to fix

34

00:02:11,066 --> 00:02:14,166

The two buckles above are the same as the one below

35

00:02:14,300 --> 00:02:16,600

There is a card slot in the middle

36

00:02:17,500 --> 00:02:20,833

You can fix this edge of the motherboard with this slot

37

00:02:22,100 --> 00:02:24,366

Now let's take a look at this fixture

38

00:02:24,933 --> 00:02:26,833

We have now fixed the upper part

39

00:02:27,033 --> 00:02:29,100

Fix the lower part by pushing

40

00:02:29,566 --> 00:02:30,766

Now it's fixed

41

00:02:31,900 --> 00:02:34,833

It also has very few points of support

42

00:02:37,100 --> 00:02:41,433

It is easy to deform when the clamp is too tight during welding

43

00:02:42,166 --> 00:02:45,633

If it is too loose, it may become unstable

44

00:02:46,533 --> 00:02:49,166

This is how our common models are used

45

00:02:49,333 --> 00:02:51,900

There may be other types in the market

46

00:02:52,933 --> 00:02:55,000

The method is basically the same

47

00:02:55,700 --> 00:03:01,733

Generally speaking, when buying a solder fixture, the factory will be giving instruction

48

00:03:02,100 --> 00:03:05,366

If you have other types I didn't mentioned it in the video

49

00:03:05,700 --> 00:03:09,500

Please refer to the instruction given by the seller to operate

50

00:03:10,133 --> 00:03:13,733

Well,so much for universal solder fixture.Thank you
