1

00:00:05,233 --> 00:00:13,866

Hello everyone, today I will demonstrate how to replace the plastic coennector on the motherboard of the mobile phone after it is damaged

2

00:00:15,100 --> 00:00:17,533

This motherboard has a connector here

3

00:00:20,500 --> 00:00:22,500

Visibly damaged by crushing

4

00:00:24,466 --> 00:00:27,100

We need to replace it

5

00:00:30,866 --> 00:00:32,466

Before replacing it

6

00:00:32,966 --> 00:00:37,266

First, tear off the foam stickers around the plastic

7

00:00:50,266 --> 00:00:52,633

Use tweezers to hold and twist

8

00:01:13,933 --> 00:01:16,500

Clean up the surroundings in the same way

9

00:01:27,900 --> 00:01:31,766

Because this foam glue will melt and shrink when heat a little

10

00:01:36,033 --> 00:01:38,666

Motherboards like iPhone series are fine

11

00:01:39,166 --> 00:01:43,666

We did not glue the components around the motherboard of the Android series

12

00:01:44,766 --> 00:01:51,900

Once you blow it until it shrinks and then blow and melt the small components, it is easy to stick it crooked

13

00:01:52,033 --> 00:01:58,833

A position shift occurs or two components in other positions stick together to cause a short circuit

14

00:01:58,900 --> 00:02:00,100

After disassembly

15

00:02:00,566 --> 00:02:04,033

We also need to clean the glue residue around a little bit

16

00:02:05,533 --> 00:02:07,600

This place needs to be cleaned up,too

17

00:02:14,866 --> 00:02:19,566

If the glue residue is far away, we don't need to clean the area like this

18

00:02:19,800 --> 00:02:22,333

We mainly clean the area where we need to solder

19

00:02:22,933 --> 00:02:30,500

Otherwise, the residual glue will stick to the solder joints we need to solder, and the connector will not be easy to solder

20

00:02:31,533 --> 00:02:33,100

Let's clean up a little

21

00:02:36,700 --> 00:02:39,733

Put a dust-free cloth on the surface of the motherboard

22

00:02:43,100 --> 00:02:45,866

Dip the brush into the PCB cleaner to clean
