1

00:00:05,000 --> 00:00:06,733

After removing the connector

2

00:00:09,600 --> 00:00:14,966

Next, we will start to clean up the residual solder on the solder joints on the motherboard

3

00:00:19,700 --> 00:00:20,966

Add some flux

4

00:00:32,300 --> 00:00:34,466

And get some low temperature solder

5

00:00:38,566 --> 00:00:42,200

Do not apply the low temperature solder directly to the motherboard

6

00:00:42,833 --> 00:00:46,266

Otherwise the solder debris will be all over the place

7

00:00:55,933 --> 00:00:59,733

After applying, use a soldering iron to iron it

8

00:01:02,600 --> 00:01:06,033

Stick some low temperature solder to the tip of the soldering iron

9

00:01:08,633 --> 00:01:10,733

Then let's flatten the solder joint

10

00:01:19,000 --> 00:01:20,233

For this big joint

11

00:01:20,600 --> 00:01:22,766

The soldering iron stays a little longer

12

00:01:25,766 --> 00:01:27,666

Small joint just go by

13

00:01:31,600 --> 00:01:33,733

We only flatten our left side

14

00:01:35,966 --> 00:01:41,966

The soldering iron and the motherboard seem to be in contact, just use solder to touch the motherboard

15

00:01:47,366 --> 00:01:49,433

Then turn the direction of the motherboard

16

00:01:51,300 --> 00:01:53,400

Continue to flatten the left side

17

00:02:07,700 --> 00:02:09,933

Some pins are not easy to melt

18

00:02:10,700 --> 00:02:12,866

Just flatten for a few more times

19

00:02:29,566 --> 00:02:31,733

Why flatten low temperature solder?

20

00:02:32,000 --> 00:02:35,666

Because the original solder on the motherboard is high temperature solder

21

00:02:36,266 --> 00:02:38,633

It is difficult to melt directly to clean up

22

00:02:38,900 --> 00:02:45,266

After flatten the low temperature tin once, the original high temperature solder melting point is reduced

23

00:02:46,000 --> 00:02:48,900

This will make it easier for us to clean up the solder

24

00:02:49,600 --> 00:02:52,733

This is the main purpose of flattening low temperature solder
