1

00:00:01,666 --> 00:00:05,300

Next we are going to re-weld the plastic connector back

2

00:00:05,533 --> 00:00:08,966

But we have completely flatten the surface of the motherboard

3

00:00:09,533 --> 00:00:11,266

No soldering tin on it

4

00:00:11,766 --> 00:00:15,333

It's necessary to add solder if we wanna weld it back

5

00:00:15,933 --> 00:00:16,733

Add solder

6

00:00:17,200 --> 00:00:19,900

If you are more proficient with the soldering iron

7

00:00:19,900 --> 00:00:23,166

We can stick a little solder directly with a soldering iron

8

00:00:23,700 --> 00:00:27,400

Flatten just like in the last video we flatten low temperature solder

9

00:00:27,566 --> 00:00:28,466

But

10

00:00:28,766 --> 00:00:31,800

Beginners are not proficient with soldering irons

11

00:00:32,066 --> 00:00:33,600

So this step is hard

12

00:00:34,133 --> 00:00:36,333

However we could use another method

13

00:00:37,000 --> 00:00:39,433

Let's find a scrapped motherboard first

14

00:00:45,466 --> 00:00:46,366

Disassemble

15

00:00:46,800 --> 00:00:49,666

Disassemble an inductive coil without glue

16

00:00:57,100 --> 00:00:58,200

Rotary-air

17

00:00:58,233 --> 00:01:02,533

The temperature and air volume are the same as when we removed the previous connector

18

00:01:02,566 --> 00:01:04,633

It will be a little slower to dismantle

19

00:01:05,100 --> 00:01:07,800

But the temperature is easier for beginners to remember

20

00:01:08,100 --> 00:01:12,233

If I say a different temperature and air volume, it may be easy to get confused

21

00:01:13,400 --> 00:01:14,466

Blow a bit longer

22

00:01:17,033 --> 00:01:19,500

Gently touch it with tweezers while blowing

23

00:01:21,366 --> 00:01:24,933

As soon as the inductor coil is loose, clip it off

24

00:01:25,133 --> 00:01:25,966

Don't break

25

00:01:31,433 --> 00:01:33,533

Now it's loose.Remove it

26

00:01:34,133 --> 00:01:35,666

Take it off and look at the back

27

00:01:38,333 --> 00:01:42,300

There are two silver-white pins on both sides of this inductor coil

28

00:01:45,366 --> 00:01:47,300

Don't break this silvery pin off it

29

00:01:49,033 --> 00:01:52,400

If it's broken, we won't be able to tin the inductor coil

30

00:01:56,433 --> 00:01:58,433

After removing the inductor coil

31

00:01:59,000 --> 00:02:02,833

Put a little medium temperature solder on the back of the inductor coil

32

00:02:08,633 --> 00:02:12,100

Use tweezers to get a small piece of medium temperature solder

33

00:02:14,666 --> 00:02:16,666

smear on this motherboard fixture

34

00:02:18,333 --> 00:02:19,366

Smear into two

35

00:02:19,366 --> 00:02:20,733

Because it has two pins

36

00:02:22,933 --> 00:02:27,833

The amount of solder paste is basically the same as the pin position of the inductor coil

37

00:02:30,200 --> 00:02:31,466

Don't need too much

38

00:02:42,133 --> 00:02:44,333

Then put the inductor on the solder paste

39

00:02:47,266 --> 00:02:50,900

Put one side on the solder paste first, then blow it

40

00:02:55,600 --> 00:02:58,733

Put the other side on the solder paste,blow it

41

00:03:06,866 --> 00:03:10,900

Now, the two lumps of solder behind the inductor coil are done
