44. Smear low melt solder on solder joints
In the video, we learn how to deal with these residual solder on the motherboard.
Detail
Comments

1

00:00:01,666 --> 00:00:06,233

Today we learn how to deal with these residual solder on the motherboard

2

00:00:14,066 --> 00:00:20,033

First, take a small lump of low-temperature tin from the bottle of low-temperature tin paste

3

00:00:23,966 --> 00:00:26,066

Put it on the motherboard fixture

4

00:00:26,733 --> 00:00:30,200

Try not to apply this low temperature tin directly to the motherboard

5

00:00:30,700 --> 00:00:38,133

If it is applied to the motherboard, it will easily flow into the gaps of the surrounding components when it is melted

6

00:00:40,133 --> 00:00:42,266

Let's apply it to the fixture first

7

00:00:42,766 --> 00:00:44,866

Clean the tip of the soldering iron

8

00:00:44,900 --> 00:00:48,666

Use the tip of a soldering iron to iron this low temperature tin

9

00:00:48,933 --> 00:00:53,100

Put a lot of this low temperature tin on the tip of the soldering iron

10

00:00:53,400 --> 00:00:56,133

Then apply it on the motherboard like this

11

00:00:56,900 --> 00:01:00,633

In this way, the solder will not flow to the surrounding

12

00:01:09,100 --> 00:01:12,433

After the low melt solder is applied to the motherboard

13

00:01:12,933 --> 00:01:15,866

This solder doesn't want to go with the soldering iron

14

00:01:16,100 --> 00:01:19,666

And many of the solder that have been applied are stuck togethe

15

00:01:19,733 --> 00:01:22,666

At this time, we add a little bit of flux

16

00:01:23,033 --> 00:01:24,000

Not too much

17

00:01:25,133 --> 00:01:26,766

Now let's apply

18

00:01:26,866 --> 00:01:34,833

When smearing, be sure to pay attention to these low-temperature tin on the soldering iron because the amount is relatively large

19

00:01:35,266 --> 00:01:38,433

Be careful not to stick to the surrounding components

20

00:01:40,133 --> 00:01:44,566

During the applying process, we need to turn this motherboard fixture

21

00:02:16,266 --> 00:02:18,400

We've smeared the solder under the chip

22

00:02:19,300 --> 00:02:20,733

Then let's do another one

23

00:03:06,800 --> 00:03:11,900

This is the low melt solder smear operation we did before dealing with the solder joints

24

00:03:13,733 --> 00:03:16,233

Why do we need to smear the low melt solder?

25

00:03:16,966 --> 00:03:22,433

Because the solder used in the production process of the motherboard is high melt solder

26

00:03:24,366 --> 00:03:29,466

After we removed the chip, the solder remaining on the motherboard will be uneven

27

00:03:30,500 --> 00:03:32,900

Then there is no way to install the chip.

28

00:03:32,900 --> 00:03:35,966

Because some joints don't even have solder on them

29

00:03:36,633 --> 00:03:39,866

We need to reball the back of the chip before we solder it back

30

00:03:40,266 --> 00:03:43,300

Or the new chip bought back has already been reballed

31

00:03:43,700 --> 00:03:46,200

When soldering, there is solder on the chip and the motherboard

32

00:03:46,466 --> 00:03:52,100

If they are welded together, there must be some places that stick and some places that won't stick

33

00:03:52,400 --> 00:03:56,333

The place where it is sticked may be short-circuited because of the tin

34

00:03:56,600 --> 00:03:59,100

So we must flatten it as much as possible

35

00:04:00,200 --> 00:04:04,700

If we do not use low melt solder to neutralize in the process of applying solder

36

00:04:05,066 --> 00:04:09,100

Then we directly flatten the high melt solder, it is difficult to melt

37

00:04:09,966 --> 00:04:12,366

So we must apply the low melt solder first
