Hello,everyone

2

00:00:03,300 --> 00:00:08,100

Today, I will show you the welding of small components on the mobile phone motherboard

3

00:00:08,800 --> 00:00:17,833

The small components on the mobile phone motherboard include resistors, capacitors, inductors,diodes and some FETs

4

00:00:18,466 --> 00:00:21,433

Fuses and inductors are most often damaged

5

00:00:21,866 --> 00:00:25,833

The probability of damage to other components is very small

6

00:00:26,066 --> 00:00:28,400

But no matter what component it is

7

00:00:28,766 --> 00:00:32,500

When repairing, the welding method is basically the same

8

00:00:33,000 --> 00:00:39,133

When welding small-sized components, the most difficult thing is the size we can see on the picture

9

00:00:39,333 --> 00:00:41,266

The smallest one,like this one

10

00:00:41,933 --> 00:00:44,666

Its size is 01005

11

00:00:45,100 --> 00:00:49,266

This is a standard size nominal for an electronic component

12

00:00:49,566 --> 00:00:52,966

01005 is in inches

13

00:00:53,366 --> 00:00:56,700

01 is 0.01 inches

14

00:00:57,033 --> 00:01:01,700

005 is 0.005 inches

15

00:01:02,233 --> 00:01:04,166

When converting to millimeters

16

00:01:04,500 --> 00:01:10,300

The size of 01005 is basically 0.3mm in length

17

00:01:11,100 --> 00:01:14,633

Then the width is 0.15mm

18

00:01:14,933 --> 00:01:16,566

It's a very small size

19

00:01:17,300 --> 00:01:18,800

Smaller than sesame

20

00:01:19,333 --> 00:01:22,566

So the welding of this component is very difficult

21

00:01:23,066 --> 00:01:28,366

Next, I will demonstrate the disassembly and assembly of this component

22

00:01:29,000 --> 00:01:32,666

First, let's remove this component from the motherboard

23

00:01:33,266 --> 00:01:39,033

When disassembling components, the more dense the components, the greater the difficulty

24

00:01:39,400 --> 00:01:44,033

A single one in a relatively open area will be much less difficult

25

00:01:44,333 --> 00:01:45,233

Like this one

26

00:01:45,466 --> 00:01:50,100

When a row like this,they are very close, it will be more difficult

27

00:01:50,133 --> 00:01:52,966

Let's find a more difficult position to operate

28

00:01:53,600 --> 00:02:00,033

In the process of disassembling damaged components, try not to touch the surrounding components crookedly

29

00:02:00,466 --> 00:02:03,400

So we need to have a good feel for this disassembly

30

00:02:04,133 --> 00:02:05,566

Straight-air hot gun

31

00:02:06,066 --> 00:02:08,666

Temperature for 450 degrees

32

00:02:08,766 --> 00:02:10,400

Maximum air volume

33

00:02:11,200 --> 00:02:17,200

Then when using sharp tweezers to clamp the components, do not clamp the upper and lower sides

34

00:02:17,800 --> 00:02:21,900

In this case, it is easy to touch the surrounding components

35

00:02:22,633 --> 00:02:24,666

So we must clip diagonally

36

00:02:24,900 --> 00:02:27,400

Put a leg in its lower left corner

37

00:02:27,700 --> 00:02:29,666

A leg on the upper right corner

38

00:02:30,066 --> 00:02:32,000

Clamp diagonally like this

39

00:02:32,233 --> 00:02:35,233

Then the air gun blows while twisting the tweezers

40

00:02:35,466 --> 00:02:37,466

You don't need to blow it all the time

41

00:02:38,133 --> 00:02:40,966

Blow it a bit and then remove it immediately

42

00:02:42,633 --> 00:02:44,766

Now the component is removed
