1

00:00:03,033 --> 00:00:04,866

After the components are removed

2

00:00:04,866 --> 00:00:09,000

We rarely measure whether it's good or bad because of the small size

3

00:00:09,366 --> 00:00:12,800

If you use a multimeter to measure these two solder joints

4

00:00:13,300 --> 00:00:17,300

Maybe two test leads touch this component, it will shift

5

00:00:17,733 --> 00:00:21,533

Or when the force is too strong, it may be crushed

6

00:00:21,933 --> 00:00:26,100

So basically you can see its original value from the drawing

7

00:00:26,433 --> 00:00:29,833

For example, what I am disassembling is a resistor

8

00:00:30,066 --> 00:00:33,366

I can see the resistance of this resistor from the drawing

9

00:00:33,466 --> 00:00:41,900

According to the resistance value on the drawing, the corresponding components can be found or the motherboard of the same model can be found

10

00:00:43,500 --> 00:00:48,900

We can take a motherboard of the same model and replace this component from the same location

11

00:00:49,433 --> 00:00:52,400

This saves a process of checking drawings

12

00:00:53,833 --> 00:00:58,033

But the motherboard we dismantled must not have entered the water

13

00:00:58,566 --> 00:01:01,566

And there is no high voltage electric shock

14

00:01:01,866 --> 00:01:04,200

This ensures that the component is good

15

00:01:04,700 --> 00:01:07,166

This is one way to replace components

16

00:01:07,766 --> 00:01:11,800

Next, let's see how to put the component I disassembled back on

17

00:01:12,466 --> 00:01:15,733

We will discard this component that was disassembled.

18

00:01:16,333 --> 00:01:19,100

Then we're ready to solder a new component back

19

00:01:19,933 --> 00:01:24,133

The solder joints of the disassembled component need to be added some solder

20

00:01:24,600 --> 00:01:29,733

When dismantling just now, we avoided touching the peripheral components crooked

21

00:01:30,266 --> 00:01:35,966

At this time, there is basically no solder on the solder joints of the disassembled components

22

00:01:36,533 --> 00:01:39,500

We must add solder on it when we weld it back

23

00:01:39,766 --> 00:01:45,766

The solder joints should be added to the size of the solder joints of the motherboard when they leave the factory

24

00:01:46,400 --> 00:01:51,466

For adding solder, we use medium melt solder of 183 degrees

25

00:01:51,766 --> 00:01:55,433

Use tweezers to get a little bit solder out of the solder bottle

26

00:01:56,066 --> 00:01:58,633

Then add on the corresponding solder joints

27

00:01:59,100 --> 00:02:02,566

Then use tweezers to distribute it to both sides

28

00:02:03,333 --> 00:02:07,300

The size of the solder joint solder should be uniform on both sides

29

00:02:08,000 --> 00:02:16,233

After the solder is applied, we use a straight air gun with a maximum air volume of 450 degrees to blow the solder

30

00:02:16,600 --> 00:02:22,833

During the process of blowing solder, you can use tweezers to gently push the solder powder in the solder

31

00:02:23,433 --> 00:02:26,100

Make it easy to stick to the solder joints

32

00:02:26,933 --> 00:02:33,566

After the solder paste is soldered to the solder joint, we can scrape off the excess around it with tweezers

33

00:02:34,166 --> 00:02:36,466

Prevents short circuits in the perimeter

34

00:02:37,233 --> 00:02:42,433

Both sides of the solder should be uniform, and the solder joints should be full

35

00:02:42,966 --> 00:02:46,700

Don't make one side big,the other side no solder

36

00:02:46,833 --> 00:02:50,366

This will make it very difficult for you to solder components

37

00:02:50,666 --> 00:02:54,600

And the solder joint with less solder may cause the soldering to fail

38

00:02:55,100 --> 00:02:57,433

This is the process of adding solder
