1

00:00:03,566 --> 00:00:06,200

Now let's learn how to solder components back

2

00:00:06,466 --> 00:00:09,500

We need to find a disassembly board of the same model

3

00:00:10,633 --> 00:00:13,266

The disassembly location must not be wrong

4

00:00:13,633 --> 00:00:17,300

This row of the same color and the same size are resistors

5

00:00:17,600 --> 00:00:19,800

But the resistance value may be different

6

00:00:20,533 --> 00:00:25,100

The character of the components may change if they are disassembled in the wrong place

7

00:00:25,300 --> 00:00:27,300

So when we replace the components

8

00:00:27,600 --> 00:00:31,566

It must be replaced in the original position from the disassembly board

9

00:00:31,933 --> 00:00:36,100

Don't randomly find one that looks the same and replace it directly

10

00:00:36,333 --> 00:00:37,700

It's easy to go wrong

11

00:00:38,366 --> 00:00:41,100

And it will cause the circuit to not work properly

12

00:00:41,633 --> 00:00:44,300

We have found a motherboard of the same model

13

00:00:44,666 --> 00:00:45,733

The same position

14

00:00:46,033 --> 00:00:48,033

Next we start to dismantle

15

00:00:48,900 --> 00:00:54,566

When disassembling this component, the method is slightly different from the previous one

16

00:00:54,733 --> 00:00:59,100

First apply flux on the surface of the component to be disassembled

17

00:01:00,766 --> 00:01:02,700

Straight-air hot gun still

18

00:01:03,233 --> 00:01:07,800

The temperature is still 450 degrees and the maximum air volume

19

00:01:08,633 --> 00:01:11,700

Blow this soldering oil onto the component first

20

00:01:12,000 --> 00:01:13,533

Then heat this component

21

00:01:14,033 --> 00:01:16,400

Take tweezers and touch the surrounding

22

00:01:16,833 --> 00:01:19,400

Because we don't need the dismantling board anymore

23

00:01:19,633 --> 00:01:21,466

We can loosen the surrounding first

24

00:01:21,600 --> 00:01:23,900

When the solder of this component melts

25

00:01:24,066 --> 00:01:25,600

Grab it with tweezers

26

00:01:26,066 --> 00:01:28,200

Don't break it as hard as before

27

00:01:28,900 --> 00:01:33,966

After the components are removed, we solder back the motherboard that needs to be repaired

28

00:01:34,500 --> 00:01:37,233

Components are placed where they need to be soldered

29

00:01:37,433 --> 00:01:39,300

Then add a little bit of flux

30

00:01:40,133 --> 00:01:42,000

The flux is to help us solder

31

00:01:42,300 --> 00:01:44,200

It can also wrap the components

32

00:01:44,500 --> 00:01:50,866

In this way, when the air gun is blowing, it will not be blown away by the large amount of wind

33

00:01:52,000 --> 00:01:53,966

Flux can be added a little more

34

00:01:54,533 --> 00:01:59,800

The temperature of soldering back is still the maximum wind of 450 degrees

35

00:02:00,066 --> 00:02:01,866

Still straight-air hot gun

36

00:02:02,066 --> 00:02:04,466

Clipped on both sides of the component

37

00:02:04,766 --> 00:02:06,533

Place it where we need to solder

38

00:02:07,133 --> 00:02:10,233

Blow for two or three seconds, then remove it

39

00:02:10,400 --> 00:02:11,666

Release the tweezers

40

00:02:11,766 --> 00:02:14,166

Touch the component lightly with tweezers

41

00:02:14,433 --> 00:02:17,066

Touch it lightly and see if it moves

42

00:02:17,200 --> 00:02:18,500

It's not moving now

43

00:02:18,766 --> 00:02:19,933

Blow it directly

44

00:02:20,833 --> 00:02:22,066

Blow to its homing

45

00:02:23,133 --> 00:02:25,333

Welding of this component is done

46

00:02:26,200 --> 00:02:27,600

We can clean this area

47

00:02:28,633 --> 00:02:33,666

When the actual maintenance, be sure to wait for the motherboard to cool down before cleaning

48

00:02:34,766 --> 00:02:37,833

Put a dust-free cloth on the surface of the motherboard

49

00:02:37,900 --> 00:02:42,366

Then the brush is dipped in the PCB cleaner and brush it with the cloth on

50

00:02:46,733 --> 00:02:48,600

This area has been cleaned

51

00:02:49,100 --> 00:02:55,033

The solder joints on both sides of the components soldered back are fuller than those from the factory

52

00:02:55,466 --> 00:02:58,400

This will make sure it's 100% solidified

53

00:02:59,100 --> 00:03:01,466

No open soldering due to less solder

54

00:03:02,033 --> 00:03:05,033

This is a process of component replacement
