1

00:00:03,066 --> 00:00:06,666

Let's find a bad motherboard to remove some empty dots

2

00:00:07,300 --> 00:00:12,966

The chip that was removed just now has a lot of empty dots on it, which can also be used

3

00:00:13,666 --> 00:00:16,966

This very round shape on the chip looks like a yellow dot

4

00:00:17,533 --> 00:00:20,000

It's actually silvery white on the front

5

00:00:20,666 --> 00:00:23,633

Use a straight air gun to remove this copper piece

6

00:00:25,866 --> 00:00:29,000

As for this chip, we're going to clip it

7

00:00:32,400 --> 00:00:33,700

It's very light

8

00:00:34,266 --> 00:00:36,033

It'll move once we blow it

9

00:00:38,800 --> 00:00:40,033

We have pikced up a dot

10

00:00:40,533 --> 00:00:43,500

Then we put the dot on the solder joint that has been dropped

11

00:00:45,433 --> 00:00:47,933

The back of the dot you just saw is red

12

00:00:49,333 --> 00:00:51,000

The front is silvery white

13

00:00:51,333 --> 00:00:53,233

We put the front silver side down

14

00:00:54,633 --> 00:00:56,033

Red side up

15

00:00:56,633 --> 00:00:58,700

Put it on the solder joint like this

16

00:01:01,766 --> 00:01:03,200

Add a little flux

17

00:01:06,366 --> 00:01:07,833

Straight-air hot gun

18

00:01:08,400 --> 00:01:10,233

450 degrees still

19

00:01:10,666 --> 00:01:11,800

Melt this dot

20

00:01:16,233 --> 00:01:17,900

So this point has been filled

21

00:01:18,666 --> 00:01:21,200

If you can't find dots, you can also buy them

22

00:01:23,200 --> 00:01:24,033

Like this

23

00:01:26,566 --> 00:01:30,300

There are a lot of regular small dots on a transparent plastic film

24

00:01:32,766 --> 00:01:36,100

Seemingly this point will be slightly larger to this motherboard

25

00:01:38,633 --> 00:01:43,533

If you want to fix some other situations such as mid-layer drop points, you can use this

26

00:01:45,533 --> 00:01:46,500

We can try one

27

00:01:47,766 --> 00:01:49,166

It looks a bit big

28

00:01:53,266 --> 00:01:54,366

It's big indeed

29

00:01:55,133 --> 00:01:57,700

It's best to remove it from the discarded motherboard

30

00:01:59,366 --> 00:02:01,600

Or remove it from the disassembled chip

31

00:02:02,666 --> 00:02:04,300

Remove another one from this chip

32

00:02:10,233 --> 00:02:11,833

A little more soldering oil

33

00:02:17,233 --> 00:02:19,666

We cannot use a soldering iron for this step

34

00:02:22,166 --> 00:02:24,333

The soldering iron may stick it away
