1

00:00:02,600 --> 00:00:06,933

When we repair mobile phone motherboards or motherboards of other models

2

00:00:07,166 --> 00:00:09,600

There may be a PCB circuit defect

3

00:00:10,200 --> 00:00:13,733

For example, this motherboard on the screen we are seeing now

4

00:00:14,366 --> 00:00:21,166

As can be seen from the drawing, from the pin above the resistor to the pin above this resistor, they are connected

5

00:00:21,833 --> 00:00:27,700

But now when I use a multimeter to measure, I find that this pin is not connected to this pin

6

00:00:28,233 --> 00:00:30,500

This is a PCB circuit defect

7

00:00:31,333 --> 00:00:38,500

If there is a PCB circuit defect, it is impossible for us to dig out the main board and reconnect the lines inside it

8

00:00:38,766 --> 00:00:42,066

If you do it,basically the board is wasted

9

00:00:42,466 --> 00:00:45,700

So we can fix it by rewiring from another location

10

00:00:46,300 --> 00:00:50,500

Next, I will demonstrate how to reconnect a line outside

11

00:00:51,033 --> 00:00:54,300

First, we prepare a little medium melt solder

12

00:00:59,133 --> 00:01:04,766

Then use 0.01 or 0.02 mm enamelled wire

13

00:01:06,700 --> 00:01:08,700

Surface must be insulated

14

00:01:11,100 --> 00:01:14,500

Place the front part of the copper wire on the solder paste

15

00:01:20,166 --> 00:01:21,366

Tin the front part

16

00:01:30,366 --> 00:01:31,900

The tip is already tinned

17

00:01:33,733 --> 00:01:36,700

Now the tinned part is basically just enough to use

18

00:01:39,433 --> 00:01:41,900

If the length of tinned part is longer

19

00:01:42,466 --> 00:01:44,300

we can cut off the excess part

20

00:01:45,166 --> 00:01:46,900

This one doesn't need to cut off

21

00:01:48,866 --> 00:01:50,566

Just get a suitable length
