1

00:00:03,733 --> 00:00:04,700

Hello,everyone

2

00:00:06,066 --> 00:00:14,066

Let me show you how to repair the wiring disconnection from the solder joints under the chip to other parts of the motherboard during the maintenance of the motherboard

3

00:00:14,833 --> 00:00:16,200

I got a motherboard now

4

00:00:16,533 --> 00:00:24,566

As it can be seen from the drawing, among the pins in the row below the chip, there is a pin which is connected to the resistor on the side

5

00:00:25,233 --> 00:00:27,800

Let's say this board has a heavy fall problem

6

00:00:28,766 --> 00:00:30,266

After we removed the chip

7

00:00:30,366 --> 00:00:33,766

It is measured that the corresponding pin has no ground value

8

00:00:34,166 --> 00:00:37,933

But the measurement from this position of the resistor has a ground value

9

00:00:38,166 --> 00:00:42,400

That means there is a disconnection from the resistor to the pin of the chip

10

00:00:42,866 --> 00:00:45,500

Then let's learn how to fix it if this happens

11

00:00:45,900 --> 00:00:49,433

To fix this disconnection, we must first remove the chip

12

00:00:51,333 --> 00:00:52,666

Straight-air hot gun

13

00:00:53,766 --> 00:00:55,200

450 degrees

14

00:00:55,900 --> 00:00:57,366

Maximum air volume

15

00:01:02,966 --> 00:01:04,333

After chip removal

16

00:01:04,800 --> 00:01:09,366

We use a soldering iron to dip a little low melt solder and flatten the solder joint

17

00:01:15,100 --> 00:01:17,933

Do not apply low melt solder directly to the motherboard

18

00:01:20,833 --> 00:01:22,700

Add a little flux to the solder joint

19

00:01:36,766 --> 00:01:38,166

Then we clean it up a bit

20

00:01:45,066 --> 00:01:49,100

On the drawing, the fourth pin from left to right on the bottom row

21

00:01:49,400 --> 00:01:51,966

This pin is connected to this resistor

22

00:01:52,700 --> 00:01:56,933

Assuming that there is a ground value when measuring from this pin of the resistor

23

00:01:57,200 --> 00:02:00,100

But when measured from this pin,no value

24

00:02:00,433 --> 00:02:04,233

That means there is a disconnection from this location to this location

25

00:02:04,500 --> 00:02:07,233

And now we're going to reconnect the line
