1

00:00:03,000 --> 00:00:05,033

Then we start to disassemble the chip

2

00:00:05,600 --> 00:00:06,466

The first step

3

00:00:07,066 --> 00:00:11,200

We need to cut the glue in the gap between the chip and the components on the edge

4

00:00:12,066 --> 00:00:14,733

For this step,we use a hot air gun

5

00:00:15,466 --> 00:00:18,466

Both rotary and straight air guns can be used

6

00:00:18,733 --> 00:00:21,333

Adjust the temperature to about 200 degrees

7

00:00:21,766 --> 00:00:24,000

Adjust the air volume to the maximum

8

00:00:24,366 --> 00:00:26,633

Soften the edge glue by blowing

9

00:00:27,000 --> 00:00:28,866

Then cut it off with a knife

10

00:00:29,266 --> 00:00:33,066

While cutting the glue, the blade should touch the chip tightly

11

00:00:33,733 --> 00:00:35,433

Stand up and touch the chip

12

00:00:38,600 --> 00:00:40,700

Then pull back and forth like this

13

00:00:42,733 --> 00:00:47,866

The position where the glue is thick should be gently cut from the surface little by little

14

00:00:52,266 --> 00:00:55,233

This step is best done under a microscope

15

00:00:55,400 --> 00:00:58,800

Because some chips have very small components on the edge

16

00:00:59,533 --> 00:01:03,933

For example,such small resistors and capacitors we see now

17

00:01:04,300 --> 00:01:08,500

If you scrape without a microscope, you may scrape them loose

18

00:01:12,966 --> 00:01:16,600

We cut the thick part downward from the surface little by little

19

00:01:16,966 --> 00:01:18,033

Don't rush

20

00:01:21,966 --> 00:01:25,900

When cutting the glue, the blade should not be inclined to the outside

21

00:01:26,500 --> 00:01:28,333

Don't lean in this direction

22

00:01:28,766 --> 00:01:30,100

Or this direction

23

00:01:30,566 --> 00:01:32,866

The handle should be parallel to the chip

24

00:01:34,366 --> 00:01:36,600

Don't turn sideways like this

25

00:01:36,633 --> 00:01:38,033

Or to another direction

26

00:01:38,733 --> 00:01:41,500

It is easy to squeeze the surrounding components

27

00:01:44,366 --> 00:01:47,333

The temperature of 200 degrees will not melt the solder

28

00:01:48,000 --> 00:01:49,800

You can cut it with confidence

29

00:01:50,300 --> 00:01:52,266

It doesn't matter if you cut it for a while

30

00:01:52,833 --> 00:01:59,533

In addition, we must pay attention to the position where our knife passes during the process of scraping the edge glue

31

00:01:59,800 --> 00:02:05,533

Use a microscope to see if there will be copper exposed in the gap after scraping the glue

32

00:02:09,133 --> 00:02:14,100

When the edge is scratched too hard, the copper will be exposed underneath

33

00:02:14,433 --> 00:02:17,800

I scratched it to an exposure on purpose to take a look

34

00:02:18,200 --> 00:02:21,633

This area has obviously exposed the color of copper

35

00:02:21,766 --> 00:02:24,000

The board has been scratched badly

36

00:02:24,200 --> 00:02:27,666

If you scratch a little harder, some lines may be broken

37

00:02:28,766 --> 00:02:32,833

We must pay close attention to the position where the blade passes when we scrape

38

00:02:33,466 --> 00:02:39,433

If there is exposed copper in any position, the force of hand pressing the blade must be lighter

39

00:02:56,200 --> 00:03:00,200

Now all the glue on the edge of the chip has been scraped off

40

00:03:04,100 --> 00:03:06,333

Next we can disassemble the chip
