1

00:00:03,100 --> 00:00:06,033

Removing the chip needs to be done on the desktop

2

00:00:06,666 --> 00:00:10,200

It is not recommended to disassemble under the microscope

3

00:00:10,533 --> 00:00:13,200

Because if you disassemble it under a microscope,

4

00:00:13,766 --> 00:00:16,600

There is no way for the air gun to stand vertically

5

00:00:16,933 --> 00:00:19,833

The temperature blown out will have some deviations

6

00:00:19,966 --> 00:00:21,533

Especially to newbies

7

00:00:21,800 --> 00:00:23,766

If the angle is not right

8

00:00:23,933 --> 00:00:25,766

when blowing with a hot air gun

9

00:00:25,966 --> 00:00:29,500

Looks like it was blown onto the chip under the microscope

10

00:00:29,833 --> 00:00:33,033

It's possible that it actually blows somewhere else

11

00:00:33,133 --> 00:00:37,066

For example, now it is blowing to the chip from this position

12

00:00:37,300 --> 00:00:40,066

What you see is that this area is heated

13

00:00:40,333 --> 00:00:43,500

The actual heating area is probably in this area

14

00:00:43,633 --> 00:00:45,933

Because it has a certain inclination

15

00:00:46,166 --> 00:00:50,933

Therefore, if you are a newbie, don't disassemble it under the microscope

16

00:00:51,400 --> 00:00:56,166

Even if an old hand disassembles it under the microscope, the temperature may deviate

17

00:00:56,466 --> 00:00:58,533

Because I need to show you the operation

18

00:00:58,800 --> 00:01:02,766

Only by operating under the microscope,you can see every detail clearly

19

00:01:02,933 --> 00:01:06,200

So you can see that I'm working under a microscope

20

00:01:06,466 --> 00:01:08,600

Next, we start to disassemble

21

00:01:08,766 --> 00:01:13,700

First, adjust the motherboard to a direction that is easier for us to operate

22

00:01:14,200 --> 00:01:17,166

Then we choose the position where we start to operate

23

00:01:18,933 --> 00:01:20,333

The corner of this area

24

00:01:20,666 --> 00:01:24,033

The area in the upper right corner is relatively empty

25

00:01:24,233 --> 00:01:27,700

There are no components, you can go down from this position

26

00:01:27,833 --> 00:01:30,233

You can also start from this area in the middle

27

00:01:30,600 --> 00:01:32,000

But don't poke too deep

28

00:01:32,133 --> 00:01:37,000

When it reaches this position, the blade squeezes the capacitors on both sides

29

00:01:37,100 --> 00:01:38,766

It is possible to loosen them

30

00:01:38,866 --> 00:01:41,733

So try not to choose to operate from this position

31

00:01:41,900 --> 00:01:45,100

Then the lower right corner is also relatively empty

32

00:01:45,200 --> 00:01:47,566

This position can also be dismantled

33

00:01:49,166 --> 00:01:52,166

But the CPU of this motherboard is behind this area

34

00:01:53,100 --> 00:01:57,366

When we first start disassembling the chip, it will be time consuming

35

00:01:57,833 --> 00:02:01,766

So we recommend choosing an area that is farther away from the CPU

36

00:02:02,933 --> 00:02:05,866

For example, the area in the upper right corner

37

00:02:06,166 --> 00:02:08,400

It will be farther away from this CPU

38

00:02:08,666 --> 00:02:10,833

I'm putting the board upside down now

39

00:02:11,766 --> 00:02:14,766

This is the lower part, this is the upper part

40

00:02:15,766 --> 00:02:17,500

This is an XR motherboard

41

00:02:18,233 --> 00:02:21,600

We blow the side away from the CPU with the hot air gun

42

00:02:22,800 --> 00:02:25,200

Let's keep blowing on this corner first

43

00:02:26,266 --> 00:02:30,400

After the blade is placed on the motherboard, press the back slightly

44

00:02:30,533 --> 00:02:33,466

This way, let the knife go straight inward

45

00:02:33,766 --> 00:02:37,100

Don't stand diagonally like this and poke in like this

46

00:02:37,366 --> 00:02:39,200

It is easy to poke the motherboard

47

00:02:40,066 --> 00:02:41,466

Flatten down a little

48

00:02:42,200 --> 00:02:43,833

Try it around gently

49

00:02:43,933 --> 00:02:47,166

Now the glue on the edges is starting to soften

50

00:02:47,333 --> 00:02:50,800

Soft but does not mean the solder has been melted

51

00:02:51,133 --> 00:02:57,066

We'll be able to poke a little deeper into it later, that means the tin is starting to melt

52

00:03:01,400 --> 00:03:02,733

It's still hard now

53

00:03:03,900 --> 00:03:06,900

Still can't poke the solder and it hasn't melted

54

00:03:11,533 --> 00:03:14,033

Now it's loose enough to poke in

55

00:03:15,433 --> 00:03:18,400

It means that the solder on this side has begun to melt

56

00:03:18,566 --> 00:03:21,233

Then we blow to other areas on a large scale

57

00:03:21,466 --> 00:03:24,166

Slowly twist the handle to pry the chip up

58

00:03:25,000 --> 00:03:26,700

Don't use too much force

59

00:03:28,200 --> 00:03:31,800

The hard disk chips from Iphone 8 to Iphone 13,

60

00:03:31,966 --> 00:03:34,666

the outermost edge is all ground pins

61

00:03:35,600 --> 00:03:38,033

The melting speed will be slightly slower

62

00:03:38,300 --> 00:03:41,066

It's easy to break off the pad when you pry too hard

63

00:03:43,466 --> 00:03:45,066

Twist the handle to pry the chip

64

00:03:47,300 --> 00:03:50,166

It doesn't matter if the pad breaks off on the side

65

00:03:50,600 --> 00:03:51,800

Blow around the edge

66

00:03:54,433 --> 00:03:55,666

We have removed this chip

67

00:03:57,100 --> 00:03:58,300

Let's look at the pads

68

00:04:00,400 --> 00:04:02,300

Luckily no break off

69

00:04:05,166 --> 00:04:07,566

This temperature is relatively suitable

70

00:04:07,666 --> 00:04:12,666

After removing it, we can find that most of the pads are relatively flat on the surface

71

00:04:13,433 --> 00:04:15,533

Individual pads show signs of melting

72

00:04:18,066 --> 00:04:19,000

This is normal

73

00:04:19,800 --> 00:04:23,633

If after removing, all the pads are in this state of melting

74

00:04:23,800 --> 00:04:27,933

It means that you did not operate properly during the prying process

75

00:04:28,333 --> 00:04:29,700

The solder has softened

76

00:04:29,900 --> 00:04:31,466

And then you still heat up

77

00:04:32,333 --> 00:04:36,600

If it is heated for a long time, the solder of chip will be extruded

78

00:04:37,366 --> 00:04:38,666

Like Xr board

79

00:04:39,133 --> 00:04:42,300

Behind its hard drive is just a wifi chip

80

00:04:44,000 --> 00:04:46,633

There are also some other chips like USB

81

00:04:47,866 --> 00:04:52,700

If you blow for too long, the solder of the area behind may be extruded

82

00:04:54,500 --> 00:05:02,200

Relatively speaking, when removing the hard disk of the Xr motherboard, the temperature is not so easy to control

83

00:05:02,766 --> 00:05:07,200

If the control is not good, there may be solder extrusion around
