1

00:00:03,700 --> 00:00:09,033

Next, let's clean up the residual solder of the motherboard pads and the pads of the chip

2

00:00:11,100 --> 00:00:12,233

Put some flux

3

00:00:13,300 --> 00:00:14,633

You can put it a bit more

4

00:00:15,066 --> 00:00:17,400

Because the size of the chip is kinda big

5

00:00:19,066 --> 00:00:21,666

Then put the desoldering wick on this motherboard

6

00:00:23,000 --> 00:00:24,533

Flatten the remaining solder

7

00:00:25,966 --> 00:00:27,766

We just cleaned it with a knife

8

00:00:28,100 --> 00:00:30,233

There is less solder remaining on it

9

00:00:30,966 --> 00:00:32,033

Easier to flatten

10

00:00:39,333 --> 00:00:40,800

The motherboard almost done

11

00:00:42,133 --> 00:00:43,833

Next let's clean up the chip

12

00:00:48,333 --> 00:00:50,266

There is basically no solder on the chip

13

00:00:50,866 --> 00:00:52,500

Just a little bit on the corner

14

00:00:56,766 --> 00:01:00,566

There is a pad on this corner, it may be a little loose when prying

15

00:01:01,366 --> 00:01:02,300

It's off now

16

00:01:03,233 --> 00:01:04,466

But that doesn't matter

17

00:01:05,166 --> 00:01:07,000

I already said it when I started

18

00:01:09,366 --> 00:01:12,566

This 110-pin hard drive after Iphone 8

19

00:01:12,700 --> 00:01:14,900

The pins of the edge are all grounded

20

00:01:19,033 --> 00:01:20,933

It doesn't matter if one or two miss

21

00:01:21,233 --> 00:01:22,433

No need to fix

22

00:01:23,100 --> 00:01:24,566

If the middle pad is off

23

00:01:26,266 --> 00:01:28,166

Like the second or third row

24

00:01:28,400 --> 00:01:30,433

We need to go to the drawing and check

25

00:01:30,966 --> 00:01:32,966

See if this pin is useful or not

26

00:01:33,633 --> 00:01:35,366

You don't have to worry about the edge

27

00:01:37,233 --> 00:01:38,600

It is clearly seen

28

00:01:38,900 --> 00:01:41,933

It is connected to the large copper foil on both sides

29

00:01:44,966 --> 00:01:46,000

Let's clean a little

30

00:01:46,133 --> 00:01:50,333

Now there is a little soldering oil, so we can't see it clearly

31

00:01:50,666 --> 00:01:52,133

Clean wouldn't help at all

32

00:01:52,666 --> 00:01:54,433

Gotta apply some soldering oil

33

00:01:55,966 --> 00:01:57,100

Now we can see

34

00:01:58,266 --> 00:02:01,766

This pad is connected to the large copper foil on this side.

35

00:02:02,300 --> 00:02:05,600

So it doesn't matter if you don't fix it if this pad is off

36

00:02:08,100 --> 00:02:11,066

After the chip and motherboard have been flattened

37

00:02:11,866 --> 00:02:14,533

Next, wash off the soldering oil

38

00:02:24,033 --> 00:02:26,366

This chip from Samsung is matte

39

00:02:29,466 --> 00:02:32,100

After cleaning, we can't see the wiring

40

00:02:41,366 --> 00:02:42,666

Let's put the chip here

41

00:02:45,233 --> 00:02:48,133

We don't need to clean the motherboard until we are ready to weld

42

00:02:50,166 --> 00:02:54,433

Because there is a thin layer of flux on the surface of the pads of the motherboard

43

00:02:54,866 --> 00:02:56,900

So the pads don't touch the air

44

00:02:57,533 --> 00:03:00,033

They are not easy to oxidize and blacken

45

00:03:00,566 --> 00:03:02,800

We have flatten the low melt solder pads

46

00:03:03,200 --> 00:03:04,766

Once it touches the air

47

00:03:05,033 --> 00:03:08,000

It'll get oxidized and blackened very easily

48

00:03:08,500 --> 00:03:10,866

We'll clean it when we're ready to install the chip

49

00:03:11,100 --> 00:03:12,800

No need to clean it now
