1

00:00:02,500 --> 00:00:04,100

Now we start to reball

2

00:00:09,066 --> 00:00:11,000

Stencil after iPhone 8

3

00:00:11,533 --> 00:00:14,000

This area of the hard disk is universal

4

00:00:14,600 --> 00:00:15,900

Any model can be used

5

00:00:23,766 --> 00:00:29,800

When reballing small chips, after the solder is applied, it should be shoveled towards the front

6

00:00:30,300 --> 00:00:33,566

This hard drive is too big, so don't shovel it

7

00:00:33,833 --> 00:00:38,400

If you shovel,half of the solder that will be shoveled out from some of the pads

8

00:00:39,233 --> 00:00:40,533

So don't shovel it

9

00:00:41,033 --> 00:00:44,833

After applying, just put the blade at a larger angle.

10

00:00:45,333 --> 00:00:46,400

Flatten back

11

00:00:47,200 --> 00:00:48,800

Flatten away the excess

12

00:00:52,033 --> 00:00:53,400

Don't wipe it either

13

00:00:54,233 --> 00:00:55,866

It will wipe out a lot

14

00:00:57,166 --> 00:00:59,533

Then use 230 degrees to reball

15

00:01:01,366 --> 00:01:04,300

Swing the hot air gun slightly faster

16

00:01:04,466 --> 00:01:07,000

Because the opening of the hard disk is larger

17

00:01:08,666 --> 00:01:10,933

And they are all in the middle of the stencil

18

00:01:12,266 --> 00:01:16,333

When your blowing temperature is too high or the speed is very slow,

19

00:01:16,733 --> 00:01:20,200

it is easy to blow the stencil to deform and distort it

20

00:01:22,933 --> 00:01:24,900

Swing the hot air gun quickly

21

00:01:30,733 --> 00:01:34,500

Do it for about a minute and then blow the solder at a fixed point

22

00:01:37,200 --> 00:01:40,766

We didn't fix the upper left corner pad because it's grounded

23

00:01:42,333 --> 00:01:44,000

It doesn't stick and it's normal

24

00:01:53,666 --> 00:01:55,833

Okay, we've done reballing

25

00:02:00,100 --> 00:02:01,900

Then take this thing off the side

26

00:02:06,233 --> 00:02:08,600

In this way, the reballing will be fuller

27

00:02:08,900 --> 00:02:09,900

And also even

28

00:02:10,566 --> 00:02:12,233

If it is shoveled or wiped,

29

00:02:12,833 --> 00:02:14,866

The pads may be uneven in size

30

00:02:15,066 --> 00:02:21,000

Then at this time, we can see that there is some glue on the corners of the chip that has not been removed

31

00:02:21,466 --> 00:02:26,633

Take a blade and cut it off to prevent it from touching the surrounding components while we install it

32

00:02:32,533 --> 00:02:33,866

Now it's clean
