1

00:00:03,000 --> 00:00:05,666

Next, we de-glue the motherboard and the chip

2

00:00:06,200 --> 00:00:07,500

Rotary-air hot gun

3

00:00:07,766 --> 00:00:09,466

About 230 degrees

4

00:00:10,033 --> 00:00:12,200

Air volume level 3-4

5

00:00:13,800 --> 00:00:15,633

Blow the middle area first

6

00:00:16,033 --> 00:00:18,066

to see if the pads have melted

7

00:00:22,833 --> 00:00:25,100

You can also use a knife to test around here

8

00:00:27,166 --> 00:00:29,433

If you see the solder is scrapped flat

9

00:00:29,766 --> 00:00:31,866

It means that the solder has melted

10

00:00:32,833 --> 00:00:34,133

Then we'll scrap around

11

00:00:40,533 --> 00:00:41,500

Blade flat

12

00:00:41,666 --> 00:00:43,100

Gently flatten back

13

00:00:44,933 --> 00:00:46,366

Don't stand too much

14

00:00:46,466 --> 00:00:49,233

It is easy to scratch the motherboard when scraping

15

00:00:49,433 --> 00:00:50,800

Don't push forward

16

00:00:51,200 --> 00:00:52,900

or with the tip of the blade

17

00:00:53,133 --> 00:00:54,100

It's not okay

18

00:00:56,566 --> 00:00:58,833

Just flatten backward like this

19

00:00:59,100 --> 00:01:02,700

As the position of the edge,the tip of the knife must touch it

20

00:01:02,800 --> 00:01:03,833

Scrape clean

21

00:01:04,500 --> 00:01:07,266

If the middle is clean but the edges are not

22

00:01:07,700 --> 00:01:09,233

The chip cannot be welded

23

00:01:26,200 --> 00:01:27,100

When it's done

24

00:01:27,566 --> 00:01:28,966

Remove the hot air gun

25

00:01:29,600 --> 00:01:31,933

The blade goes back and forth to scrape

26

00:01:32,300 --> 00:01:34,466

Take away the dirt left on the motherboard

27

00:01:41,466 --> 00:01:43,633

Then scrape the dirt onto this fixture

28

00:01:48,166 --> 00:01:49,033

Clean it up

29

00:02:00,433 --> 00:02:01,400

The top part

30

00:02:01,866 --> 00:02:04,966

When we scrape to the bottom, we can't scrape the edge

31

00:02:05,966 --> 00:02:07,866

So we're going to reverse the direction

32

00:02:18,066 --> 00:02:20,866

The area where the blade passes must be smoothed

33

00:02:21,833 --> 00:02:25,700

Scrape the pads flat to indicate that the glue has been scraped clean

34

00:02:26,266 --> 00:02:32,000

When you scrape, you may find that there are a lot of pads will be taken away directly with the blade

35

00:02:32,933 --> 00:02:34,333

You don't need to worry about it

36

00:02:38,566 --> 00:02:40,866

99% of them they are idle pads

37

00:02:45,166 --> 00:02:50,033

Even if you scratched off some pads, that's because it has been fallened hard before

38

00:02:50,866 --> 00:02:53,266

There is no problem with the method like mine

39

00:02:54,266 --> 00:02:56,200

It's impossible to scratch off the pads

40

00:02:56,866 --> 00:02:58,266

No exposed copper

41

00:02:59,666 --> 00:03:01,366

Pads are not tha much fragile

42

00:03:01,833 --> 00:03:04,566

If there is a large area of the exposed copper

43

00:03:05,300 --> 00:03:10,866

By that time,if there is a or some pads off, which may be because of your scrapping technique

44

00:03:11,266 --> 00:03:13,066

We scrape the chip in the same way

45

00:03:17,233 --> 00:03:18,800

It's easier than motherboard

46

00:03:22,666 --> 00:03:27,333

Because there are no other components around the chip to prevent us from operating

47

00:04:04,700 --> 00:04:05,666

As always

48

00:04:05,900 --> 00:04:09,366

At the end, scrape it back and forth with a knife

49

00:04:10,066 --> 00:04:12,566

Take away all the solder and glue on this
