86.Cleaning the flatten back pads
In the video, we will learn to cleaning the flatten back pads.
Detail
Comments

1

00:00:06,666 --> 00:00:10,500

Find a clean dust-free cloth and wrap the chip inside the cloth

2

00:00:12,900 --> 00:00:15,333

Wait for it to cool completely before cleaning

3

00:00:15,933 --> 00:00:21,166

Because the chip is still relatively hot, if you suddenly wash it with PCB cleaner

4

00:00:21,800 --> 00:00:25,066

Cooling down too fast may cause the chip crystal to break

5

00:00:25,866 --> 00:00:28,333

We'll wait for it to cool completely before cleaning

6

00:00:28,766 --> 00:00:31,300

Cover the surface with a cloth and brush

7

00:00:34,300 --> 00:00:37,966

Use the dust-free cloth to stick out the dirt in this hole

8

00:00:50,366 --> 00:00:53,266

Check again to see if there is any dirt in the hole

9

00:00:54,133 --> 00:00:58,766

If there is dirt, we will use a sharp blade to pick it up again

10

00:01:00,300 --> 00:01:04,133

There is a hole in this area with a black glue block in it

11

00:01:05,100 --> 00:01:06,500

Pick out with the blade

12

00:01:13,200 --> 00:01:16,066

There are some bits of solder slag on the side

13

00:01:19,900 --> 00:01:21,633

It doesn't have much impact

14

00:01:22,100 --> 00:01:24,066

Because we'll be reballing later

15

00:01:28,100 --> 00:01:30,600

Mainly to see if there is glue in the hole

16

00:01:34,800 --> 00:01:37,966

After cleaning, we flatten the solder on the back

17

00:01:44,800 --> 00:01:48,200

This step must be before the middle layer of reballing

18

00:02:05,733 --> 00:02:10,433

When flattening the solder, pay attention to do it on this silicone pad

19

00:02:11,133 --> 00:02:14,333

The silicone pad can give it a heat dissipation effect

20

00:02:21,333 --> 00:02:23,300

Next we clean the chip again

21

00:02:41,900 --> 00:02:43,166

Almost cleaned up
