1

00:00:03,300 --> 00:00:04,733

Now the chip is clean

2

00:00:05,066 --> 00:00:08,133

Then we will start to use a special tool to reball it

3

00:00:09,100 --> 00:00:10,233

Now let's see the step

4

00:00:11,433 --> 00:00:13,900

This is called CPU reballing platform

5

00:00:16,700 --> 00:00:20,266

Now A8 has been divided into upper and lower layers

6

00:00:20,433 --> 00:00:24,100

A special gasket like this should be placed under it

7

00:00:24,933 --> 00:00:26,100

Just like this

8

00:00:27,833 --> 00:00:31,433

It is to replace the thickness of the upper or lower layer

9

00:00:31,933 --> 00:00:34,000

This stainless steel sheet

10

00:00:37,900 --> 00:00:43,233

This tool has the label 8901234 on it

11

00:00:45,333 --> 00:00:49,966

Then there is also a corresponding 8901234 here

12

00:00:50,766 --> 00:00:55,066

A8 CPU, the two corners correspond to the position of 8

13

00:00:56,133 --> 00:00:57,833

Place just like this

14

00:00:59,166 --> 00:01:01,266

Then use our dedicated stencil

15

00:01:03,266 --> 00:01:05,100

We gotta clean the stencil as well

16

00:01:05,433 --> 00:01:07,266

To prevent some dirt in the hole

17

00:01:16,333 --> 00:01:18,366

Then put the stencil on the card slot

18

00:01:22,666 --> 00:01:27,233

As soon as you put on it, the pads in the middle will automatically correspond

19

00:01:27,466 --> 00:01:29,200

May be slightly tilted

20

00:01:30,466 --> 00:01:32,366

This will not affect reballing

21

00:01:32,666 --> 00:01:34,166

After putting it on

22

00:01:38,033 --> 00:01:40,133

There's a big magnet on the base

23

00:01:40,133 --> 00:01:42,966

Then the above is the template for stucking chip

24

00:01:42,966 --> 00:01:47,633

As long as you put it on, the magnet will suck the stencil very tightly

25

00:01:47,900 --> 00:01:51,033

Basically, it won't move during this process

26

00:01:51,066 --> 00:01:53,866

It is much more stable than the manual reballing

27

00:01:54,133 --> 00:01:56,533

And the stencil alignment is also very simple

28

00:01:58,133 --> 00:02:01,233

There is a magnet in the middle of the stencil to stuck it

29

00:02:01,533 --> 00:02:05,700

You don't have to use tweezers to press it, it won't hang in the air

30

00:02:06,366 --> 00:02:09,800

This tool is very suitable for beginners to practice

31

00:02:10,466 --> 00:02:17,633

Reballing on the CPU without the guidance of others, it may not be successful if you practice for a week or two

32

00:02:18,300 --> 00:02:23,000

With this tool, even a beginner can get it done in half a day at most

33

00:02:38,633 --> 00:02:40,933

All solder is smoothed and shoveled

34

00:02:49,700 --> 00:02:51,800

So much easier than manual tools

35

00:02:54,500 --> 00:02:56,100

Wipe off the excess

36

00:02:56,633 --> 00:02:58,833

Don't worry about the stencil shifting

37

00:02:59,566 --> 00:03:00,866

Then we start blowing

38

00:03:01,733 --> 00:03:04,900

Because there will be some heat dissipation on this base

39

00:03:05,266 --> 00:03:08,566

We need to increase the temperature of reballing a little bit

40

00:03:08,566 --> 00:03:10,466

Around 250 degrees

41

00:03:10,600 --> 00:03:13,200

The air volume is still level 3-4

42

00:03:14,200 --> 00:03:17,033

Blow a large area for about 1 minute first

43

00:03:28,233 --> 00:03:30,633

Then slowly blow the solder to a corner

44

00:03:38,933 --> 00:03:46,033

At this time, individual pads may be a little dirty or the position of the stencil may be slightly off

45

00:03:48,066 --> 00:03:53,233

There is no need to remove the stencil even if the individual pads are not glued on

46

00:03:54,100 --> 00:03:56,600

Put a little solder oil at this position

47

00:03:57,833 --> 00:03:59,700

There are 2 pads off here

48

00:03:59,733 --> 00:04:04,133

Add a little bit of solder oil to them and blow it with an air gun

49

00:04:04,400 --> 00:04:06,533

Gently touch it with tweezers

50

00:04:07,166 --> 00:04:09,400

Let it return to the position of the pad

51

00:04:09,600 --> 00:04:10,500

Push a bit

52

00:04:11,433 --> 00:04:12,166

It's glued

53

00:04:12,733 --> 00:04:16,733

In this way you don't have to take the stencil off and reball it

54

00:04:20,400 --> 00:04:22,033

Chip reballing is done

55

00:04:22,200 --> 00:04:23,466

Pick up this stencil

56

00:04:26,366 --> 00:04:27,666

Still the same way

57

00:04:27,800 --> 00:04:30,933

See if there is any excess solder bead in this hole

58

00:04:31,933 --> 00:04:36,066

Looking at it from the side, it is obvious that there is nothing

59

00:04:37,066 --> 00:04:37,433

Done
