1

00:00:03,000 --> 00:00:04,666

After the chip is reballed

2

00:00:05,033 --> 00:00:07,600

Next we can solder the chip to the motherboard

3

00:00:08,033 --> 00:00:10,700

Before welding,we gotta clean the motherboard

4

00:00:11,233 --> 00:00:13,100

To clean off the dirt

5

00:00:18,700 --> 00:00:22,166

There are also some solder beads of different sizes on the pads

6

00:00:22,933 --> 00:00:25,066

Let's flatten them with the desolder wick

7

00:00:33,200 --> 00:00:34,800

Must be gentle to do it

8

00:00:35,233 --> 00:00:38,833

The soldering iron only needs to be placed on the copper wire

9

00:00:39,100 --> 00:00:40,500

Do not press on it

10

00:00:49,166 --> 00:00:54,633

During the flattening process, a lot of idle pads will be removed by the desoldering wick

11

00:00:55,500 --> 00:00:56,500

This is normal

12

00:00:56,966 --> 00:00:58,000

Don't mind it

13

00:01:04,866 --> 00:01:08,166

Put a dust-free cloth on it to absorb the welding oil

14

00:01:13,400 --> 00:01:16,233

By doing so,the motherboard will be clean

15

00:01:16,733 --> 00:01:22,166

If the idle pad sticks to the pad, scrape it off with a blade and an air gun

16

00:01:22,600 --> 00:01:24,100

Straight-air hot gun

17

00:01:26,100 --> 00:01:27,733

The temperature doesn't matter

18

00:01:27,866 --> 00:01:30,300

Just blow the solder and pick it off

19

00:01:34,566 --> 00:01:37,300

The glue next to the flash chip is still there

20

00:01:40,000 --> 00:01:41,966

Brush sideways with a brush

21

00:01:45,933 --> 00:01:47,333

Now it's clean

22

00:01:49,633 --> 00:01:50,900

Put some flux

23

00:01:54,966 --> 00:01:59,133

When adding the flux, we also need a hot air gun to heat the board

24

00:02:01,333 --> 00:02:03,333

So the flux would be more even

25

00:02:06,100 --> 00:02:08,200

Thickness is easier to control

26

00:02:08,600 --> 00:02:13,233

If you apply flux directly on the cold board, there will be a thick layer

27

00:02:17,433 --> 00:02:22,300

When applying this large chip, you can bend the needle of the syringe a little bit

28

00:02:27,166 --> 00:02:30,733

There must be a certain curvature so that it is easier to apply

29

00:02:38,666 --> 00:02:40,433

Wipe the excess to the edge

30

00:02:41,900 --> 00:02:43,033

Don't be too thick

31

00:02:48,000 --> 00:02:49,700

Pay attention to the idle pads

32

00:02:50,233 --> 00:02:52,333

If there is,remove it
