1

00:00:03,933 --> 00:00:06,600

Let's flatten the low melt solder and clean it

2

00:00:08,200 --> 00:00:11,633

Remember to flatten the low melt solder first and then clean

3

00:00:13,533 --> 00:00:15,933

Because the tin on this pad is uneven,

4

00:00:16,200 --> 00:00:17,933

some is large and some is small

5

00:00:18,700 --> 00:00:21,333

When washing directly, and the brush is too hard

6

00:00:21,533 --> 00:00:23,200

it will easily break off

7

00:00:23,700 --> 00:00:27,033

So we're going to flatten the low melt solder to every pad

8

00:00:27,900 --> 00:00:31,033

scrape until the pad is more rounded and then clean it

9

00:00:31,800 --> 00:00:34,366

This pad will not have any resistance

10

00:00:36,133 --> 00:00:38,233

It doesn't break off easily when brushing

11

00:00:40,766 --> 00:00:43,866

There is a lot of tin on the pads, when we brush it,

12

00:00:45,766 --> 00:00:48,600

When the resistance of this tin is great

13

00:00:49,466 --> 00:00:51,800

It's also easy to wipe the pad off.

14

00:00:55,700 --> 00:00:59,466

We just use the soldering iron to drag off this glass crystal

15

00:01:10,966 --> 00:01:12,700

wait for it to cool down

16

00:01:29,400 --> 00:01:32,633

After cooling, wrap the chip with a dust-free cloth

17

00:01:35,300 --> 00:01:37,200

and clean through this cloth

18

00:01:46,733 --> 00:01:51,066

Use a cloth to stick away the soldering oil and the glue residues

19

00:02:11,133 --> 00:02:13,466

If we cannot stick the last few pieces,

20

00:02:14,033 --> 00:02:15,500

We're going to use a brush

21

00:02:27,300 --> 00:02:30,833

In this area, there are a few more pads broke off just now.

22

00:02:31,333 --> 00:02:33,633

The pad break-of may happen when we brush

23

00:02:34,033 --> 00:02:36,066

For example, the point we see now

24

00:02:36,066 --> 00:02:38,066

is obviously higher than other points

25

00:02:38,800 --> 00:02:40,033

It's a little looser

26

00:03:53,533 --> 00:03:55,000

ok, after cleaning

27

00:03:55,000 --> 00:03:58,433

We can see there're some places where the glue is still a little thick

28

00:03:59,566 --> 00:04:00,933

Let's keep scraping

29

00:04:13,700 --> 00:04:15,533

First clean the fixture

30

00:05:40,866 --> 00:05:43,266

The edge on this side looks a little darker

31

00:05:44,400 --> 00:05:45,600

it should be glue

32

00:05:55,533 --> 00:05:57,166

After the glue is scraped off,

33

00:05:57,700 --> 00:05:59,633

it becomes that kind of black scum
