1

00:00:02,500 --> 00:00:04,333

Next, we will reball the chip

2

00:00:08,400 --> 00:00:13,333

After the chip cools down, use a dustless cloth to dab some PCB cleaner on the board

3

00:00:13,633 --> 00:00:15,500

Wipe off the dirt on the chip

4

00:00:25,633 --> 00:00:29,066

After cleaning, find a paper towel and place it under the chip

5

00:00:44,900 --> 00:00:46,400

Now let's clean the stencil

6

00:00:46,700 --> 00:00:50,900

Wipe the front and back of the area that used to reball with a dustless cloth

7

00:00:57,000 --> 00:00:59,800

Check carefully to see if there is any dirt in the hole.

8

00:01:02,333 --> 00:01:04,666

For example, in this place, it is obvious that

9

00:01:04,666 --> 00:01:06,266

there is still so black residue

10

00:01:06,933 --> 00:01:10,433

This is definitely not good, let's continue to wipe it again

11

00:01:32,400 --> 00:01:35,033

Ok, now the stencil is basically clean

12

00:01:35,300 --> 00:01:36,900

Then we start to reball

13

00:02:04,766 --> 00:02:07,566

Press the two sides of the chip with a curved tweezer,

14

00:02:09,733 --> 00:02:13,266

and align the holes of the stencil with the pads at the bottom

15

00:02:17,533 --> 00:02:18,800

Apply the tin paste

16

00:02:34,700 --> 00:02:36,433

Scoop out the excess tin paste

17

00:02:41,366 --> 00:02:45,800

Find a dry, dustless cloth that has not been soaked with PCB cleaner,

18

00:02:45,800 --> 00:02:48,366

and wipe the excess tin paste on this edge

19

00:02:51,900 --> 00:02:55,400

Do not wipe with a cloth that has been soaked in PCB cleaner

20

00:02:56,466 --> 00:02:59,466

Otherwise, the PCB cleaner will dilute the tin paste,

21

00:02:59,766 --> 00:03:02,500

as a result, the tin paste will seep everywhere

22

00:03:02,800 --> 00:03:05,066

from the gap between the stencil and the chip

23

00:03:05,533 --> 00:03:09,266

And it will lead to uneven size of the pads or short circuit

24

00:03:10,333 --> 00:03:14,166

We use the rotary air gun with temperature of 230 degrees

25

00:03:14,500 --> 00:03:16,200

to blow the large area

26

00:03:44,200 --> 00:03:48,400

Blow for about 1 minute, then put the nozzle against a corner of the chip

27

00:03:51,900 --> 00:03:56,766

After the solder melts, blow for a few more seconds, and then remove the nozzle

28

00:04:00,166 --> 00:04:03,933

After removing the nozzle, wait a little longer for ten seconds,

29

00:04:03,933 --> 00:04:05,533

and then release the tweezer

30

00:04:06,900 --> 00:04:08,966

If you release the tweezer too early,

31

00:04:08,966 --> 00:04:11,033

when the solder has not yet solidified,

32

00:04:11,300 --> 00:04:13,966

the stencil is deformed a little and bounces,

33

00:04:14,133 --> 00:04:15,966

and the solder sticks together again

34

00:04:20,000 --> 00:04:24,400

Press the outside, lift the stencil from our direction, and pull out the chip

35

00:04:27,700 --> 00:04:28,933

Well, it's done

36

00:04:29,533 --> 00:04:30,966

But we missed one pad

37

00:04:31,133 --> 00:04:33,833

It may be that there is a little dirt on this pad

38

00:04:35,000 --> 00:04:36,166

Let's repair it

39

00:04:45,500 --> 00:04:49,566

Of course, you can also directly put the stencil back and blow it again

40

00:04:57,433 --> 00:04:59,533

First, a little bit of soldering oil

41

00:05:04,566 --> 00:05:07,300

Let's reheat and blow this tin bead back into place

42

00:05:07,566 --> 00:05:09,366

because it looks a little crooked

43

00:05:17,300 --> 00:05:19,700

The fourth in the second row in the lower right corner

44

00:05:27,400 --> 00:05:31,366

There is a black glue under the tin bead, so it can't be blown up

45

00:05:32,100 --> 00:05:33,900

and this tin bead is too small

46

00:05:46,833 --> 00:05:48,933

In this case, we can only take out the tin bead

47

00:05:48,933 --> 00:05:50,700

and put a new tin bead on it.

48

00:06:01,366 --> 00:06:03,100

Drag a knife on the paper towel

49

00:06:06,900 --> 00:06:07,966

blow this tin paste

50

00:06:12,033 --> 00:06:15,566

In this way, all kinds of tin beads of different sizes are made.

51

00:06:16,900 --> 00:06:20,666

Then we put the chip aside and find one that is basically the same size

52

00:06:30,933 --> 00:06:33,033

The tip of the tweezer must be clean

53

00:06:38,566 --> 00:06:40,733

This tin bead is just suitable

54

00:06:45,833 --> 00:06:47,833

When we make up this kind of tin beads,

55

00:06:47,866 --> 00:06:53,000

we still use the temperature of the air gun just now to blow it, 230 degrees

56

00:06:53,033 --> 00:06:55,433

But you have to reduce the air volume to the minimum,

57

00:06:55,566 --> 00:06:57,600

because the tin beads are loose now

58

00:06:57,933 --> 00:07:00,766

and can easily be blown away when the wind is strong

59

00:07:01,100 --> 00:07:02,333

Let's start to blow

60

00:07:03,766 --> 00:07:04,866

ok, it's glued

61

00:07:16,133 --> 00:07:18,600

In fact, if you are unstable with the tweezers,

62

00:07:18,633 --> 00:07:21,666

you will not be able to repair it after tryingmany times

63

00:07:21,933 --> 00:07:24,866

So you can directly use a soldering iron to flatten it

64

00:07:25,000 --> 00:07:26,200

and reball it again

65

00:07:30,800 --> 00:07:32,833

Okay, the chip reballing is done
