    125. Scraping the pads on flex cable
    we ground off the chip on the new screen,we have to remove the chip from the old screen and install it on it.
    38 person
    Collection
    Detail
    Comments

    1

    00:00:03,033 --> 00:00:06,566

    The chip has been ground so that the pads are clearly visible

    2

    00:00:06,733 --> 00:00:07,866

    Then at this time,

    3

    00:00:07,933 --> 00:00:10,866

    we should not continue to use the grinding pen to grind,

    4

    00:00:11,133 --> 00:00:14,066

    otherwise the flex cable will easily be scratched

    5

    00:00:15,600 --> 00:00:19,233

    We find a size 16 blade that is slightly sharper,

    6

    00:00:19,633 --> 00:00:22,033

    and scrape off the uneven pads on the chip

    7

    00:02:22,666 --> 00:02:25,200

    This is the green skin left on the PCB

    8

    00:03:28,466 --> 00:03:31,400

    Okay, so, we ground off the chip on the new screen

    9

    00:03:39,333 --> 00:03:40,800

    This chip is useless

    10

    00:03:42,833 --> 00:03:46,600

    We have to remove the chip from the old screen and install it on it
