1

00:00:00,166 --> 00:00:04,133

In this lesson, we will talk about the display power chip

2

00:00:04,300 --> 00:00:08,600

In mobile phones, in order to better control the work of the display,

3

00:00:08,866 --> 00:00:14,200

the display power supply chip is independently designed to provide power for the display

4

00:00:14,400 --> 00:00:16,800

We usually call it a display chip

5

00:00:17,300 --> 00:00:20,733

Its voltage has positive voltage and negative voltage

6

00:00:21,000 --> 00:00:22,000

They are different

7

00:00:22,566 --> 00:00:23,733

During maintenance,

8

00:00:23,833 --> 00:00:29,766

we need to pay attention to whether the mobile phone uses an LCD screen or an OLED screen

9

00:00:30,366 --> 00:00:34,566

The operating voltages required for these two screens are different

10

00:00:34,766 --> 00:00:39,266

For example, the picture on the left shows a display power supply chip

11

00:00:39,366 --> 00:00:40,333

Let's take a look

12

00:00:40,500 --> 00:00:42,566

Inside the OLED screen,

13

00:00:42,566 --> 00:00:46,200

the pixel control unit has its own light-emitting function,

14

00:00:46,466 --> 00:00:47,833

using only one chip

15

00:00:48,666 --> 00:00:51,300

This display chip has some characteristics

16

00:00:51,633 --> 00:00:54,666

First, it is surrounded by three large inductors,

17

00:00:54,966 --> 00:00:55,900

like this chip,

18

00:00:56,000 --> 00:00:58,200

there are three large inductors here,

19

00:00:58,200 --> 00:01:00,166

surrounding this display chip

20

00:01:00,966 --> 00:01:04,066

And it is commonly a square 16-pin chip

21

00:01:06,700 --> 00:01:08,900

For example, the one on the left,

22

00:01:09,666 --> 00:01:13,466

its models start with PF31, 32B,

23

00:01:13,600 --> 00:01:23,400

or DOS04, DOS05, or TPS65633, or TPS65634, etc.

24

00:01:23,766 --> 00:01:25,566

This is its appearance feature,

25

00:01:25,866 --> 00:01:27,666

surrounded by three inductors,

26

00:01:27,700 --> 00:01:34,533

square, 16 pins, starting with PF, DOS, or TPS

27

00:01:35,066 --> 00:01:40,100

Tits is also a display power supply chip, its number is DOS04

28

00:01:40,400 --> 00:01:42,600

It's surrounded by three inductors

29

00:01:43,366 --> 00:01:45,566

This is an OLED screen

30

00:01:46,300 --> 00:01:48,033

Let's look at the inductors

31

00:01:48,400 --> 00:01:53,900

There are three inductors, then this chip is TPS65634

32

00:01:54,633 --> 00:01:58,900

This is also a display power supply chip, LCD backlight screen,

33

00:01:59,366 --> 00:02:06,266

it uses the power supply method of display chip plus backlight chip to provide power to the screen

34

00:02:06,533 --> 00:02:10,000

the display chip of the backlight screen has a characteristic

35

00:02:10,233 --> 00:02:13,800

It is generally a rectangle with a large inductor on the side

36

00:02:14,000 --> 00:02:18,500

The common models include GR, TPS, and LM

37

00:02:19,000 --> 00:02:24,333

the display power supply and backlight power supply of Huawei mobile phones are integrated

38

00:02:24,733 --> 00:02:26,066

That is to say,

39

00:02:26,266 --> 00:02:30,900

the display power supply and the backlight power supply are completed by one chip,

40

00:02:31,066 --> 00:02:33,400

and the LM series chips are used

41

00:02:33,600 --> 00:02:34,500

For example,

42

00:02:34,533 --> 00:02:37,400

the chip starting with GR in the picture integrates

43

00:02:37,400 --> 00:02:40,500

the display power supply and the backlight power supply,

44

00:02:40,866 --> 00:02:43,033

and has a large inductor next to it

45

00:02:44,600 --> 00:02:47,866

This chip, LM36274,

46

00:02:47,866 --> 00:02:52,033

is the power supply chip for the display screen on the mainboard of the mobile phone

47

00:02:52,600 --> 00:02:55,333

It is also the power supply chip for the backlight

48

00:02:55,833 --> 00:02:59,100

there is a large inductor next to it and a diode

49

00:02:59,766 --> 00:03:01,533

Okay, that's it for this lesson
