1

00:00:00,300 --> 00:00:03,233

We will talk about the main audio chips in this lesson

2

00:00:04,200 --> 00:00:07,000

The main audio chip is also called the big audio

3

00:00:07,966 --> 00:00:12,133

The common code names in the circuit are Codec or CDC

4

00:00:15,066 --> 00:00:18,700

It is mainly responsible for processing the microphone signal,

5

00:00:18,833 --> 00:00:22,000

the earpiece signal, the earphone signal

6

00:00:22,833 --> 00:00:24,900

The microphone collects the sound,

7

00:00:25,266 --> 00:00:28,033

and the earpiece is a component that can hear the sound

8

00:00:28,033 --> 00:00:31,066

without turning on the hands-free when making a call,

9

00:00:31,233 --> 00:00:32,966

also called a small speaker

10

00:00:36,033 --> 00:00:40,000

For example, the one shown in the picture on the right is a small audio

11

00:00:40,966 --> 00:00:46,033

The audio chips of Oppo and Vivo's early mobile phone using the MTK platform

12

00:00:46,066 --> 00:00:48,100

are integrated inside the power supply

13

00:00:48,333 --> 00:00:54,766

At present, Xiaomi, Huawei, Oppo, and Vivo mostly use independent audio chips

14

00:00:55,366 --> 00:00:58,933

Qualcomm platform commonly used WCD series chips

15

00:00:59,266 --> 00:01:03,400

For example, the picture on the right is WCD9340

16

00:01:04,300 --> 00:01:11,633

Hi6403 and Hi6405 audio chips are commonly used in Hisilicon Huawei series

17

00:01:12,433 --> 00:01:15,900

Some Hisilicon platform use power integrated audio,

18

00:01:16,000 --> 00:01:18,366

such as Hi6555

19

00:01:18,600 --> 00:01:22,766

MediaTek platforms commonly integrate audio chip inside the power supply

20

00:01:23,566 --> 00:01:27,266

The picture on the right is from the WCD Qualcomm platform

21

00:01:27,600 --> 00:01:30,800

This is Hisilicon Hi6403

22

00:01:32,700 --> 00:01:37,633

This Hi6555 is the power chip integrated with big audio

23

00:01:40,300 --> 00:01:41,700

This is MTK,

24

00:01:41,833 --> 00:01:45,166

most of them integrate audio chips inside the power supply

25

00:01:45,700 --> 00:01:47,366

Ok, that's it for this lesson
