In this lesson, we will talk about the audio power amplifier chips

2

00:00:05,600 --> 00:00:09,566

Audio amplifier chip is also known as ringtone amplifier chip,

3

00:00:09,733 --> 00:00:11,166

or small audio

4

00:00:13,200 --> 00:00:17,200

It amplifies the power of the external sound and sends it to the speakers

5

00:00:18,333 --> 00:00:19,300

For example,

6

00:00:19,433 --> 00:00:24,466

the chip that makes the speaker sound when we play music is the audio amplifier chip

7

00:00:25,100 --> 00:00:29,166

It can also restore sounds and play ringtones for incoming calls

8

00:00:33,533 --> 00:00:36,600

How do we quickly find the audio amplifier chip in the mainboard?

9

00:00:37,466 --> 00:00:39,000

It has large inductors,

10

00:00:39,000 --> 00:00:42,766

large capacitors, and two black insurances surrounded

11

00:00:44,066 --> 00:00:47,900

Some mobile phone chips are designed on the charging connector small board

12

00:00:48,800 --> 00:00:51,500

In the picture on the left, this is a small chip

13

00:00:57,400 --> 00:01:00,833

Generally, there are at least three large capacitors

14

00:01:01,000 --> 00:01:04,233

There is a large inductor and two insurances

15

00:01:04,666 --> 00:01:07,733

These two insurances are actually inductor beads

16

00:01:08,033 --> 00:01:09,733

This is its appearance

17

00:01:10,100 --> 00:01:15,333

From the appearance, we can roughly judge that this chip is a ringtone amplifier chip

18

00:01:18,866 --> 00:01:22,666

The two pictures show the two on-board ringtone amplifier chips

19

00:01:25,833 --> 00:01:27,966

This is the ringtone amplifier chip,

20

00:01:28,366 --> 00:01:32,200

this is an inductor here, there are three capacitors here

21

00:01:32,433 --> 00:01:34,733

There are two small insurance inductors,

22

00:01:34,866 --> 00:01:36,433

which are magnetic beads

23

00:01:37,000 --> 00:01:38,233

In the picture on the right,

24

00:01:38,833 --> 00:01:41,466

we can see that the audio chip has 4 capacitors,

25

00:01:41,900 --> 00:01:44,833

a large inductor, and two brown inductors

26

00:01:52,066 --> 00:01:54,400

In this picture, where is the audio chip?

27

00:01:59,666 --> 00:02:01,866

This is a charging connector interface,

28

00:02:02,133 --> 00:02:04,633

also called a charging connector small board,

29

00:02:04,833 --> 00:02:07,066

with a charging connector welded on it

30

00:02:07,566 --> 00:02:09,633

This is its audio amplifier chip

31

00:02:11,100 --> 00:02:13,633

There are two black fuses around the chip,

32

00:02:13,633 --> 00:02:16,700

a large inductor, and two large capacitors

33

00:02:18,666 --> 00:02:23,100

This is the ringtone amplifier chip welded on the charging connector small board

34

00:02:25,000 --> 00:02:26,966

Ok, that's it for this lesson
