In this lesson, we talk about the current and maintenance direction of each stage of startup

2

00:00:05,633 --> 00:00:10,166

When the mobile phone is turned on, the current at each stage is different,

3

00:00:10,433 --> 00:00:12,833

which means that the circuit state is different

4

00:00:14,500 --> 00:00:17,333

First, let's take a look at the standby of the phone

5

00:00:18,766 --> 00:00:19,966

What is standby?

6

00:00:20,300 --> 00:00:23,066

It is to use the battery to supply power to the main board,

7

00:00:23,433 --> 00:00:25,333

without pressing the power button,

8

00:00:25,633 --> 00:00:27,933

the main board supplies power to the charging chip,

9

00:00:27,933 --> 00:00:30,033

converts it into the main power supply,

10

00:00:30,366 --> 00:00:32,700

and then supplies it to the power supply chip,

11

00:00:32,900 --> 00:00:36,366

but at this time, this line has no current,

12

00:00:36,633 --> 00:00:38,966

which is called the standby circuit

13

00:00:40,066 --> 00:00:43,133

The current of the standby circuit is 0mA

14

00:00:43,433 --> 00:00:45,366

After we press the power button,

15

00:00:45,600 --> 00:00:47,933

we pull down the power button signal

16

00:00:50,566 --> 00:00:55,400

The power output from the power chip is the power output controlled by the power-on signal

17

00:00:55,900 --> 00:00:58,300

If it is only the power supply output,

18

00:00:59,833 --> 00:01:02,033

its current is about 30 mA

19

00:01:05,633 --> 00:01:07,466

After the power supply works,

20

00:01:07,466 --> 00:01:12,433

the clock circuit works, and the current will be about 40 mA

21

00:01:14,800 --> 00:01:19,333

After the reset circuit works, the current is about 60 mA

22

00:01:19,633 --> 00:01:23,600

That is to say, when we press the power button to supply power,

23

00:01:24,033 --> 00:01:26,733

the clock is normal, the reset is normal,

24

00:01:27,033 --> 00:01:31,200

and the current of this mobile phone should be at least about 60 mA

25

00:01:32,166 --> 00:01:36,933

The CPU starts to work, and the current is generally around 80 mA

26

00:01:37,766 --> 00:01:41,933

When we see that the current of a mobile phone jumps to 80 mA,

27

00:01:42,200 --> 00:01:45,100

it means that the CPU has reached a working state

28

00:01:47,000 --> 00:01:51,466

Of course, 80 mA is the state of an inport mode of the CPU

29

00:01:51,733 --> 00:01:54,000

The circuit only goes to the CPU

30

00:02:00,833 --> 00:02:03,366

If the CPU cannot recognize the hard disk,

31

00:02:03,433 --> 00:02:06,000

it will only load its own written program,

32

00:02:06,266 --> 00:02:07,933

which is called the inport mode

33

00:02:09,200 --> 00:02:11,666

Let's take a look at what is inport mode

34

00:02:12,933 --> 00:02:18,966

If a mobile phone does not recognize the hard disk and the current is around 80 or 100 mA,

35

00:02:20,800 --> 00:02:23,166

we can connect the mobile phone to the computer,

36

00:02:24,200 --> 00:02:27,900

find the device manager in the computer management page of the computer,

37

00:02:28,400 --> 00:02:31,533

and the inport mode will appear in the device manager

38

00:02:45,633 --> 00:02:47,900

If it is a Qualcomm platform processor,

39

00:02:48,133 --> 00:02:51,966

its inport mode is HS-USB 9008,

40

00:02:52,233 --> 00:02:53,833

Qualcomm is the brand logo,

41

00:02:54,200 --> 00:02:57,133

and 9008 is the specific sorting port,

42

00:02:57,433 --> 00:03:00,366

If it is the processor of the Hisilicon platform,

43

00:03:00,600 --> 00:03:05,066

then it will enter the port mode of HUAWEI USB COM 1.0

44

00:03:10,100 --> 00:03:11,666

After the CPU works,

45

00:03:11,800 --> 00:03:14,500

it needs to read the boot program in the hard disk

46

00:03:14,966 --> 00:03:18,466

At this time, the current of the mobile phone will jump,

47

00:03:18,600 --> 00:03:21,633

generally higher than 120mA

48

00:03:26,733 --> 00:03:32,666

and the current will continue to jump between 100 and 300 mA for a period of time,

49

00:03:32,866 --> 00:03:34,700

this is the loading program

50

00:03:34,966 --> 00:03:36,600

The display starts to work,

51

00:03:36,800 --> 00:03:41,200

the current is about 300 mA, and the display will light up

52

00:03:41,833 --> 00:03:44,800

This is the current at each stage of the phone's startup

53

00:03:46,000 --> 00:03:48,566

Generally, when we study the current to this stage,

54

00:03:48,833 --> 00:03:51,266

we have a general direction for maintenance

55

00:03:52,166 --> 00:03:53,866

In the actual maintenance,

56

00:03:54,166 --> 00:03:57,766

at which stage are most of the problems of Android phones?

57

00:03:58,300 --> 00:04:02,566

It is the stage from the start of the CPU to the start of the display,

58

00:04:03,466 --> 00:04:07,233

and the current is from 100 to 300 mA

59

00:04:07,766 --> 00:04:09,800

Okay, that's all for this lesson
