1

00:00:00,200 --> 00:00:04,133

The relevant circuit of the trigger small current is shown in the block diagram

2

00:00:05,000 --> 00:00:08,566

To repair the faults of no booting caused by trigger small current,

3

00:00:08,766 --> 00:00:11,733

we need to check the circuit diagram in the actual maintenance

4

00:00:12,100 --> 00:00:17,966

Let's take a look at how the circuit diagrams of different brands of mobile phones express the working principle

5

00:00:18,533 --> 00:00:22,266

We learned earlier that the direct circuit of the trigger small current fault

6

00:00:22,266 --> 00:00:26,433

is the power supply chip and the power supply provided by the power supply chip,

7

00:00:26,566 --> 00:00:30,800

the clock signal, the reset signal, the maintain signal,

8

00:00:30,800 --> 00:00:32,833

and the data communication

9

00:00:37,833 --> 00:00:39,166

Then let's take a look

10

00:00:39,900 --> 00:00:42,833

We open Xinzhizao intelligent maintenance system,

11

00:00:43,133 --> 00:00:45,466

For example, the Xiaomi 10 mobile phone,

12

00:00:45,900 --> 00:00:48,166

open its mainboard schematic diagram,

13

00:00:48,433 --> 00:00:52,166

let's see where the circuit related to the trigger small current is

14

00:00:52,600 --> 00:00:54,233

Open the component map,

15

00:00:54,400 --> 00:00:56,700

we have to find its power supply first

16

00:00:57,266 --> 00:01:00,633

The U4700 here is a small power supply

17

00:01:02,933 --> 00:01:05,900

The U4200 here is the main power chip

18

00:01:10,933 --> 00:01:14,433

We search for U4200 in the schematic diagram

19

00:01:15,000 --> 00:01:18,600

It automatically searched for U4200_2,

20

00:01:19,166 --> 00:01:23,366

which is the second part of the description of the chip U4200

21

00:01:25,233 --> 00:01:29,166

The model of this chip is PM8250

22

00:01:34,533 --> 00:01:37,733

But this part is not the description of the main power supply

23

00:01:38,900 --> 00:01:43,700

We see that there are some boot signals called PHONE_ON_N

24

00:01:44,400 --> 00:01:48,000

There are also reset signals, maintain signals

25

00:01:48,333 --> 00:01:50,433

This part is not the power supply part,

26

00:01:50,933 --> 00:01:53,366

we have to find its power supply part first

27

00:01:53,833 --> 00:01:56,833

The U4200_4 is the fourth part

28

00:01:57,300 --> 00:01:59,233

How do we understand this diagram?

29

00:02:00,333 --> 00:02:04,266

To its left is the power supply input, VPH_PWR,

30

00:02:04,833 --> 00:02:06,600

which is the main power supply

31

00:02:07,800 --> 00:02:10,500

The main power supply is supplied to this power chip

32

00:02:10,900 --> 00:02:13,500

When this power supply chip meets the conditions,

33

00:02:14,000 --> 00:02:16,433

such as pin 19 and pin 5,

34

00:02:16,966 --> 00:02:25,733

it outputs a power supply called VREG_S1A_S2A_S3A_0P75 through the energy storage inductor,

35

00:02:26,300 --> 00:02:27,566

and S means switch

36

00:02:28,366 --> 00:02:30,333

Is this the CPU power supply?

37

00:02:30,900 --> 00:02:35,000

We can double click on it and it jumps to page 38

38

00:02:35,333 --> 00:02:38,500

There is a chip here, U3100,

39

00:02:38,766 --> 00:02:40,366

so what kind of chip is it?

40

00:02:40,500 --> 00:02:45,066

SM8250, this is Qualcomm's CPU model,

41

00:02:45,333 --> 00:02:49,133

its power supply is supplied to the P33 pin of the CPU

42

00:02:49,666 --> 00:02:50,933

Come back here again

43

00:02:51,100 --> 00:02:56,233

The power output of this power supply is VREG_S4A_1P8

44

00:02:56,433 --> 00:02:59,633

1P8 means that the voltage is 1.8V

45

00:03:00,066 --> 00:03:03,733

Is this 1.8V power supply supplied to the CPU?

46

00:03:04,333 --> 00:03:07,800

Of course, it gives U4700_7

47

00:03:08,166 --> 00:03:13,166

Its model number is PM8150A, a small power supply

48

00:03:13,566 --> 00:03:16,266

We have to find out if it is going to the CPU

49

00:03:16,433 --> 00:03:18,866

If this power supply goes to the CPU,

50

00:03:19,166 --> 00:03:21,700

it means that it's the power supply of the CPU

51

00:03:22,200 --> 00:03:24,500

We searched until we found the CPU,

52

00:03:24,833 --> 00:03:26,500

which leads to a lot of chips

53

00:03:26,633 --> 00:03:28,000

Such as audio chip,

54

00:03:28,533 --> 00:03:31,266

this is a page of the audio chip description

55

00:03:31,666 --> 00:03:36,933

It leads to a small audio, leads to a hall sensor, and leads to a seat

56

00:03:42,100 --> 00:03:44,266

Here, it leads to a wifi chip,

57

00:03:46,166 --> 00:03:47,366

we find it here,

58

00:03:47,866 --> 00:03:50,833

SM8250 is the CPU

59

00:03:52,900 --> 00:03:56,933

This VREG_S4A_1P8 is the line just now

60

00:03:57,433 --> 00:03:59,466

It comes from a large power supply and

61

00:03:59,466 --> 00:04:05,200

comes through a zero-ohm resistor to the A12 and A29 pins of the CPU

62

00:04:05,533 --> 00:04:08,166

It is also the power supply of the CPU

63

00:04:08,466 --> 00:04:10,733

We're going back to where it outputs power,

64

00:04:10,933 --> 00:04:13,133

so we're going to hurry up here

65

00:04:13,666 --> 00:04:19,066

That is, the power output from the main power supply of the U4200

66

00:04:20,166 --> 00:04:21,566

By looking at the line,

67

00:04:21,900 --> 00:04:24,833

it is actually the power supply of the CPU

68

00:04:25,266 --> 00:04:29,900

Is the VREG_S5A_1P9 powered by the CPU?

69

00:04:30,533 --> 00:04:32,533

Here is a method for your reference

70

00:04:33,133 --> 00:04:38,900

When we see that a power supply starts from the power supply and is finally connected to the CPU,

71

00:04:39,800 --> 00:04:43,966

then this power supply can be regarded as the power supply of the CPU

72

00:04:44,800 --> 00:04:46,200

It's just such simple

73

00:04:46,866 --> 00:04:50,966

Well, we see it coming to the small power supply U4200

74

00:04:51,066 --> 00:04:55,366

It arrives at U2400 after going to many places

75

00:04:55,700 --> 00:04:57,466

That's not what we're looking for

76

00:04:58,000 --> 00:05:00,166

Let's see if it reaches the CPU

77

00:05:00,700 --> 00:05:05,800

After running around, we found VREG_S5A_1P9,

78

00:05:06,333 --> 00:05:08,033

it didn't reach the CPU,

79

00:05:08,333 --> 00:05:11,033

so it is not the power supply of the CPU

80

00:05:11,866 --> 00:05:13,733

Okay, that's it for this lesson
