    27. How to quickly find the power supply of a chip
    In this lesson, we talk about the description of trigger small currents in circuit diagrams.
    19 person
    Collection
    Detail
    Comments

    1

    00:00:00,266 --> 00:00:01,200

    In this lesson,

    2

    00:00:01,266 --> 00:00:05,233

    we talk about the description of trigger small current in the circuit diagrams

    3

    00:00:05,600 --> 00:00:10,033

    We talked about the two power supply lines from the power supply to the CPU in the last class,

    4

    00:00:10,400 --> 00:00:11,733

    we will continue to see

    5

    00:00:12,100 --> 00:00:17,933

    The power output from the U4200 power supply chip is the power supply begins with VREG

    6

    00:00:18,466 --> 00:00:24,533

    For example, VREG_S6A_0P9, 0.9V power supply

    7

    00:00:24,866 --> 00:00:28,033

    And this, 0.75V power supply

    8

    00:00:28,766 --> 00:00:33,166

    And this, VREG_S10_A0P75

    9

    00:00:33,566 --> 00:00:36,833

    This is the power output from the switching power supply module

    10

    00:00:36,833 --> 00:00:38,400

    integrated inside the power chip

    11

    00:00:38,900 --> 00:00:40,500

    Does it power the CPU?

    12

    00:00:40,766 --> 00:00:42,600

    We have another way to determine

    13

    00:00:44,766 --> 00:00:48,700

    Our last lesson was by looking at the wiring that goes to the CPU,

    14

    00:00:48,900 --> 00:00:53,433

    which goes to the U4200, to the U2400,

    15

    00:00:53,433 --> 00:00:54,466

    and back again

    16

    00:00:55,500 --> 00:00:58,100

    We found that it doesn't go to the CPU,

    17

    00:00:58,200 --> 00:01:00,233

    then it's not powering the CPU

    18

    00:01:04,233 --> 00:01:06,933

    Let's see if the power supply goes to the CPU

    19

    00:01:07,966 --> 00:01:10,533

    This power supply goes to page 38

    20

    00:01:11,200 --> 00:01:12,600

    What is this chip called?

    21

    00:01:12,966 --> 00:01:15,633

    It is called SM8250

    22

    00:01:15,833 --> 00:01:18,933

    It is the seventh part of the description of this chip

    23

    00:01:19,566 --> 00:01:22,166

    U3100 is the CPU

    24

    00:01:25,333 --> 00:01:28,700

    OK, here we say another way to determine the CPU power

    25

    00:01:30,966 --> 00:01:33,733

    First, we need to know which chip is the CPU

    26

    00:01:34,500 --> 00:01:37,833

    The chip is generally rectangular on the circuit diagram,

    27

    00:01:38,266 --> 00:01:40,966

    the position number will be marked on the top of it,

    28

    00:01:41,100 --> 00:01:43,700

    and the model number will be marked on the bottom

    29

    00:01:44,400 --> 00:01:46,500

    For example, this CPU,

    30

    00:01:46,800 --> 00:01:49,700

    U3100 is its position number,

    31

    00:01:50,133 --> 00:01:52,866

    SM8250 is its model

    32

    00:01:53,133 --> 00:01:56,433

    From this, we can know that this is the CPU

    33

    00:01:56,900 --> 00:01:59,600

    So what about the power supply to    the CPU?

    34

    00:02:00,133 --> 00:02:03,733

    We can search for the position number of the CPU in the circuit diagram

    35

    00:02:03,933 --> 00:02:08,600

    For example, this power supply is supplied to the W29 pin of the CPU,

    36

    00:02:09,033 --> 00:02:12,200

    then this power supply is the power supply of the CPU

    37

    00:02:13,333 --> 00:02:14,400

    In the same way,

    38

    00:02:14,566 --> 00:02:21,233

    the 0.75V power supply begins with VREG is given to the A22 pin of the CPU

    39

    00:02:24,966 --> 00:02:27,366

    This is also the CPU power supply,

    40

    00:02:27,866 --> 00:02:30,233

    this is also the CPU power supply,

    41

    00:02:30,766 --> 00:02:33,300

    and this one is also the CPU power supply

    42

    00:02:40,700 --> 00:02:43,000

    This is the description page of the chip

    43

    00:02:43,266 --> 00:02:48,666

    This 0.88V power supply is supplied to the AC33 pin of the CPU

    44

    00:02:49,133 --> 00:02:52,700

    Similarly, this is also the CPU power supply,

    45

    00:02:53,033 --> 00:02:55,633

    and this one is also the CPU power supply

    46

    00:03:00,400 --> 00:03:03,766

    If the CPU wants to work, it needs to be powered,

    47

    00:03:04,033 --> 00:03:06,133

    and the power is provided by other chips

    48

    00:03:06,366 --> 00:03:08,866

    The CPU itself does not output power,

    49

    00:03:09,000 --> 00:03:11,233

    it can only output control signals

    50

    00:03:11,600 --> 00:03:15,100

    Therefore, its power supply is provided by the power chip,

    51

    00:03:15,366 --> 00:03:19,000

    the main power supply or the auxiliary power supply

    52

    00:03:20,133 --> 00:03:23,033

    This is how to quickly find the power supply on a chip,

    53

    00:03:23,266 --> 00:03:25,100

    that is to find the chip first,

    54

    00:03:25,300 --> 00:03:28,766

    and then see which power supplies are connected to this chip

    55

    00:03:29,933 --> 00:03:31,733

    Okay, that's it for this lesson
